Free Practice Questions for The Open Group OGEA-101 Exam

The four dimensions used to scope an architecture are Breadth, Depth, Time Period, and Architecture Domains1, p. 8.

Breadth refers to the extent of the enterprise covered by the architecture, which can range from a specific business unit to the entire organization1, p. 8.

Depth refers to the level of detail and completeness of the architecture, which can vary depending on the purpose, scope, and stakeholders of the architecture1, p. 8.

Time Period refers to the temporal aspects of the architecture, such as the current state, the target state, and the transition plan1, p. 8.

Architecture Domains refers to the classification of the architecture into four domains: Business, Data, Application, and Technology1, p. 8.

These four dimensions help define the scope and boundaries of the architecture and ensure that it meets the needs and expectations of the stakeholders.

1: The Open Group (2018). The TOGAF® Standard, Version 9.2. 1

Risk management is a generic technique that can be applied across all phases of the Architecture Development Method (ADM), as well as in the Preliminary Phase and the Requirements Management Phase2. Risk management involves the following steps1:

•Risk identification: This step involves identifying the potential risks that may affect the architecture project, such as technical, business, organizational, environmental, or legal risks. The risks can be identified through various sources, such as stakeholder interviews, workshops, surveys, checklists, historical data, or expert judgment.

•Risk classification: This step involves categorizing the risks based on their nature, source, impact, and priority. The risks can be classified according to different criteria, such as time, cost, scope, quality, security, or compliance. The classification helps in prioritizing the risks and allocating resources and efforts to address them effectively.

•Initial risk assessment: This step involves assessing the likelihood and impact of each risk, and determining the initial level of risk. The likelihood is the probability of the risk occurring, and the impact is the severity of the consequences if the risk occurs. The initial level of risk is the product of the likelihood and impact, and it indicates the urgency and importance of the risk. The initial risk assessment helps in identifying the most critical risks that need immediate attention and mitigation.

Statements 1 and 3 highlight the value and necessity for Architecture Governance to be adopted within organizations. Architecture Governance is the practice and orientation by which Enterprise Architectures and other architectures are managed and controlled at an enterprise-wide level12. It ensures that architectural decisions are aligned with the organization’s strategy, objectives, and standards. Architecture Governance also involves establishing and maintaining processes, decision-making, and mechanisms to avoid or minimize potential conflicts of interest, such as between different stakeholders, business units, or projects34. Moreover, Architecture Governance requires transparency and accountability for all actions implemented and their decision support, so that they can be inspected and evaluated by authorized parties, such as auditors, regulators, or customers5 . References:

•The TOGAF Standard, Version 9.2 - Architecture Governance - The Open Group

•Architecture Governance - The Open Group

•Tutorial: Governance in TOGAF’s Architecture Development Method (ADM)

•Architecture Governance in TOGAF: Ensuring Effective Management and Compliance

•The TOGAF Standard, Version 9.2 - Definitions - The Open Group

•[Architecture Governance in TOGAF: Ensuring Alignment and Control]

The Business Transformation Readiness Assessment technique is used to evaluate the readiness of the organization to undergo change and to identify the actions needed to increase the likelihood of a successful business transformation. These actions should be incorporated in the Implementation and Migration Plan, which is the detailed plan to transition from the Baseline Architecture to the Target Architecture. The Implementation and Migration Plan also includes the Transition Architectures, the Architecture Building Blocks, the Work Packages, the Implementation Governance Model, and the Architecture Contract12 References: 1: The TOGAF Standard, Version 9.2, Part III: ADM Guidelines and Techniques, Chapter 27: Business Transformation Readiness Assessment 2: The TOGAF Standard, Version 9.2, Part II: Architecture Development Method (ADM), Chapter 21: Phase F: Migration Planning

A-Architecture Repository: This is a part of the Architecture Metamodel that contains artifacts structured according to the metamodel. It includes the Architecture Landscape which is adopted by the enterprise and governed by certain standards and practices.

B-Governing Board: The Governing Board ensures visibility and escalation, meaning it oversees and manages the capability of the architecture landscape. It plays a crucial role in governance.

C-Enterprise Capability: This refers to how well an enterprise can execute its mission, meet business objectives or satisfy its stakeholders’ needs and expectations. It’s influenced by both internal factors (like resources, processes) and external ones (like market trends).

TOGAF Version 9.1, Chapter 34: 1

The chart illustrates an important TOGAF concept: ADM phases can operate concurrently or iteratively rather than strictly sequentially. The diagram shows Phase A activities occurring first, after which the architecture development phases (Business, Data, Application, and Technology Architectures) overlap in time. This overlap demonstrates how architecture development work may proceed in parallel as information becomes available, allowing architects to refine and coordinate the candidate architecture more efficiently.

TOGAF explicitly supports iteration and concurrency across ADM phases. While the phases are presented in a logical order, they are not intended to be executed in a rigid step-by-step sequence in all situations. Instead, architects may work across several phases simultaneously to address dependencies, refine requirements, and accelerate the development of the candidate architecture and roadmap.

Option A best reflects this principle because it acknowledges that phases may run together as part of an iterative architecture development process until a coherent candidate architecture is produced and validated. Option B is incorrect because TOGAF does not mandate the use of specific project management tools such as Gantt charts. Option C is incorrect because the ADM is not strictly sequential. Option D is incorrect because the duration of phases is not fixed in TOGAF.

Therefore, the chart illustrates the concept that ADM phases may be executed concurrently to develop and validate the candidate architecture.

In TOGAF, Architecture Principles are created to provide a clear and stable foundation for architecture work across the enterprise. Their purpose is to guide decision-making and establish a shared understanding of the rules and boundaries within which architecture and business change should take place. The best answer is A because Architecture Principles are intended to create a common basis for governance and direction, ensuring that architecture supports the control and evolution of the enterprise in line with its strategic goals.

Option B is incorrect because documenting likely impacts belongs more appropriately to the Implications section of an individual principle, not to the overall purpose of creating a set of principles. Option C is also incorrect because while principles may reflect aspects of enterprise culture and values, that is not their main purpose. Option D refers more closely to an Architecture Contract, which is a formal agreement between sponsors and architects or implementation organizations.

A defined set of principles helps ensure consistency, improves governance, supports compliance, and aligns architecture decisions with business direction. In this way, principles act as a decision framework for the enterprise. Therefore, the correct completion of the sentence is establish a common understanding of how to control the business in pursuit of strategic goals.

Comprehensive and Detailed Explanation

In TOGAF, Architecture Contracts are agreements between development partners and sponsors that define:

The deliverables to be produced.

The quality expectations.

The fitness-for-purpose of the architecture.

The responsibilities of each party and the governance arrangements.

Architecture Contracts are a key part of Phase G: Implementation Governance, where they are used to manage and control architecture implementation. They help ensure that implementation projects remain aligned with the approved Target Architecture and business objectives.

They serve as the formal mechanism for:

Validating that architecture deliverables meet stakeholder expectations.

Providing a measurable basis for conformance assessment.

Supporting architecture governance by linking architectural intent with project execution.

Why the other options are incorrect

B. The Statement of Architecture Work: This defines the scope, approach, resources, and schedule for architecture work, but it is not a joint agreement on deliverables and fitness-for-purpose.

C. Service Level Agreements (SLAs): These are agreements about operational service levels (e.g., availability, performance), not architecture deliverables.

D. Non-disclosure Agreement (NDA): This protects confidentiality of information but does not address deliverables, quality, or fitness-for-purpose of an architecture.

References

The Open Group, TOGAF® Standard, Version 9.2, Part II: ADM — Phase G: Implementation Governance, Architecture Contracts.

The Open Group, TOGAF® 9 Certified Study Guide — explanation of Architecture Contracts as a governance tool.

The Architecture Repository is the structural framework defined by TOGAF to store, manage, and leverage architecture artifacts, including reference models, standards, governance logs, and deliverables.

The Architecture Capability refers to governance and processes.

The Architecture Landscape shows Strategic, Segment, and Capability architectures, not storage.

The Enterprise Architecture Capability Model is not a defined TOGAF concept.
