Free Practice Questions for Salesforce MuleSoft-Platform-Architect-I Exam

Explanation

Correct Answer: Set a timeout of 100ms; that leaves 400ms for other two downstream APIs to complete

*****************************************

Key details to take from the given scenario:

>> Upstream API's designed SLA is 500ms (median). Lets ignore maximum SLA response times.

>> This API calls 3 downstream APIs sequentially and all these are of similar complexity.

>> The first downstream API is offering median SLA of 100ms, 80th percentile: 500ms; 95th percentile: 1000ms.

Based on the above details:

>> We can rule out the option which is suggesting to set 50ms timeout. Because, if the median SLA itself being offered is 100ms then most of the calls are going to timeout and time gets wasted in retried them and eventually gets exhausted with all retries. Even if some retries gets successful, the remaining time wont leave enough room for 2nd and 3rd downstream APIs to respond within time.

>> The option suggesting to NOT set a timeout as the invocation of this API is mandatory and so we must wait until it responds is silly. As not setting time out would go against the good implementation pattern and moreover if the first API is not responding within its offered median SLA 100ms then most probably it would either respond in 500ms (80th percentile) or 1000ms (95th percentile). In BOTH cases, getting a successful response from 1st downstream API does NO GOOD because already by this time the Upstream API SLA of 500 ms is breached. There is no time left to call 2nd and 3rd downstream APIs.

>> It is NOT true that no timeout is possible to meet the upstream APIs desired SLA.

As 1st downstream API is offering its median SLA of 100ms, it means MOST of the time we would get the responses within that time. So, setting a timeout of 100ms would be ideal for MOST calls as it leaves enough room of 400ms for remaining 2 downstream API calls.

To accommodate the new requirement of allowing updates to existing quotes, the following actions should be taken:

Update the RAML Definition (Option C):

The RAML specification defines the structure and behavior of the API. Adding a new method (such as PUT or PATCH) for updating quotes requires modifying the RAML to include this new endpoint. This ensures the API specification is up-to-date and accurately reflects the new functionality.

Update the API Implementation (Option A):

Once the RAML is updated, the backend API implementation must also be modified to handle the new update requests. This could involve adding logic to process and validate update requests, connect to necessary backend resources, and apply the changes to existing quotes.

Explanation of Incorrect Options:

Option B (removing and creating new clients) is unnecessary; client applications can remain as they are, with no need for complete replacement.

Option D (deprecating existing versions) may not be required if backward compatibility is maintained.

Option E (adding a new policy) does not facilitate functional changes and is unrelated to implementing the update feature.

ReferencesFor more details on updating RAML definitions and API implementations, refer to MuleSoft’s API Design documentation on RAML and RESTful API practices​.

Default Alert Capabilities in Anypoint Platform:

Anypoint Platform provides out-of-the-box alerting capabilities for monitoring API invocation conditions, including setting thresholds for the number of invocations.

Alerts can be configured for conditions such as high or low traffic (invocations exceeding or falling below a defined threshold).

Evaluating the Options:

Option A: Anypoint Platform does not provide direct alerting based on DNS records.

Option B: Anypoint Platform does not provide default alerts based on whether invocations use TLS/SSL; this would require custom configuration.

Option C: Geolocation-based alerting is not natively supported in Anypoint Platform.

Option D (Correct Answer): Alerts based on API invocation thresholds (e.g., invocations falling below a set threshold) are supported and can be configured as part of the default Anypoint alerting functionality.

Conclusion:

Option D is correct, as Anypoint Platform allows configuring alerts based on the number of API invocations falling below or exceeding a threshold.

Refer to MuleSoft's documentation on Anypoint Monitoring and alert configurations for more details.

Explanation

Correct Answer: The remaining capacity allowed by the API implementation.

*****************************************

>> Reference: https://docs.mulesoft.com/api-manager/2.x/rate-limiting-and-throttling-sla-based-policies#response-headers

Explanation

Correct Answer: Increase the size of the CloudHub worker(s)

*****************************************

The key details that we can take out from the given scenario are:

>> API implementation uses a database bulk insert command to submit all the purchase data to a database

>> JDBC driver processes the data into a set of several temporary disk files on the CloudHub worker

>> Sometimes a request fails and the logs show a message indicating an out-of-file-space message

Based on above details:

>> Both auto-scaling options does NOT help because we cannot set auto-scaling rules based on error messages. Auto-scaling rules are kicked-off based on CPU/Memory usages and not due to some given error or disk space issues.

>> Increasing the number of CloudHub workers also does NOT help here because the reason for the failure is not due to performance aspects w.r.t CPU or Memory. It is due to disk-space.

>> Moreover, the API is doing bulk insert to submit the received batch data. Which means, all data is handled by ONE worker only at a time. So, the disk space issue should be tackled on "per worker" basis. Having multiple workers does not help as the batch may still fail on any worker when disk is out of space on that particular worker.

Therefore, the right way to deal this issue and resolve this is to increase the vCore size of the worker so that a new worker with more disk space will be provisioned.

Explanation

Correct Answer: Manually provisioned customer-hosted runtime plane and customer-hosted control plane

*****************************************

There are two key factors that are to be taken into consideration from the scenario given in the question.

>> Company requires both data and metadata to be resided within the corporate firewall

>> Company would like to go with customer-hosted infrastructure.

Any deployment model that is to deal with the cloud directly or indirectly (Mulesoft-hosted or Customer's own cloud like Azure, AWS) will have to share atleast the metadata.

Application data can be controlled inside firewall by having Mule Runtimes on customer hosted runtime plane. But if we go with Mulsoft-hosted/ Cloud-based control plane, the control plane required atleast some minimum level of metadata to be sent outside the corporate firewall.

As the customer requirement is pretty clear about the data and metadata both to be within the corporate firewall, even though customer wants to move to production as quickly as possible, unfortunately due to the nature of their security requirements, they have no other option but to go with manually provisioned customer-hosted runtime plane and customer-hosted control plane.

Explanation

Correct Answer: The test runs immediately after the Mule application has been compiled and packaged

*****************************************

>> Integration tests are the last layer of tests we need to add to be fully covered.

>> These tests actually run against Mule running with your full configuration in place and are tested from external source as they work in PROD.

>> These tests exercise the application as a whole with actual transports enabled. So, external systems are affected when these tests run.

So, these tests do NOT run immediately after the Mule application has been compiled and packaged.

FYI... Unit Tests are the one that run immediately after the Mule application has been compiled and packaged.

Understanding JSON Threat Protection Policies:

JSON Threat Protection policies are used to protect APIs from attacks that exploit JSON payloads, such as oversized payloads, deeply nested objects, and excessive array elements. This helps prevent Denial of Service (DoS) attacks and other malicious payload-related threats.

These policies are typically applied to safeguard APIs that are directly exposed to external clients, where the risk of receiving malicious payloads is highest.

API-led Connectivity Layers:

Experience Layer: This layer is designed to expose APIs to end-users or external API clients, often acting as the interface that interacts with users or applications.

Process Layer: This layer is used for orchestration and aggregation of data from various System APIs, typically operating within a trusted environment and not directly exposed to external clients.

System Layer: This layer provides access to backend systems and databases, often within the organization’s secure environment and not directly accessible to external clients.

Evaluating the Options:

Option A (All layers): While JSON Threat Protection can technically be applied to all layers, it is most commonly applied at the Experience layer, where APIs are exposed to external traffic and are more vulnerable to attacks.

Option B (System layer): The System layer is generally not exposed to external clients directly, so JSON Threat Protection is less critical here.

Option C (Process layer): Similar to the System layer, the Process layer is typically internal and not exposed directly to external clients, so JSON Threat Protection is less commonly applied.

Option D (Correct Answer): The Experience layer is the correct answer because it is the layer that directly interacts with external clients, making it the primary target for malicious payloads. Applying JSON Threat Protection here effectively protects the application network from external threats.

Conclusion:

Option D is the correct answer, as the Experience layer is the most common layer for applying JSON Threat Protection policies to protect against external attacks.

For further reference, consult MuleSoft's documentation on API security policies and best practices for securing APIs at the Experience layer.
