Which of the following letters represents the scope lines?
A
B
C
D
The Answer Is:
BExplanation:
The diagram provided is a Function Analysis System Technique (FAST) diagram, a key tool in Value Methodology’s Function Analysis phase, as taught in the VMF 1 course (Core Competency #2). FAST diagrams map the relationships between functions of a system, with the horizontal axis showing the “how-why” logic (critical path) and the vertical axis showing supporting functions. The vertical demarcations on the left and right of a FAST diagram are calledscope lines, which define the boundaries of the study. According to SAVE International’s Value Methodology Standard, “scope lines indicate the limits of the system or project being analyzed, separating the functions within the study’s scope from external functions or assumptions.” This was previously established in Question 15, where scope lines were identified as the correct term for these vertical demarcations.
In the FAST diagram:
The dashed vertical lines on the left and right are labeledB(left) andD(right). These lines define the scope of the study, with functions inside the lines (e.g., E, F, G, J, L, M, N, O) being within the study’s focus, while functions outside (e.g., P, Q, R) are external assumptions or higher-level objectives.
Ais a horizontal line at the bottom, representing the boundary of the diagram but not the scope lines.
Cis an arrow indicating the direction of the “why” axis (left), not a scope line.
Since the question asks for the letter that “represents the scope lines,” and both B and D are scope lines, the correct answer must be one of these. However, the options only allow for one letter to be selected, and in FAST diagramming convention, the left scope line (B) is often emphasized as the primary boundary for defining the study’s starting point (e.g., the higher-order function E, as identified in Question 18). Thus,Bis the most appropriate choice among the options provided.
Option A (A) is incorrect because A is a horizontal line, not a vertical scope line.
Option B (B) is correct, as B is the left vertical scope line, marking the boundary of the study’s scope.
Option C (C) is incorrect because C is an arrow, not a scope line.
Option D (D) is also a scope line (the right boundary), but since only one letter can be selected and B is the left scope line (often the primary focus in FAST diagramming), B is chosen. If the question intended to allow both B and D, the phrasing would need adjustment.
In which phase is a large quantity of ideas or alternatives generated to accomplish the functions?
Creativity Phase
Presentation Phase
Evaluation Phase
Function Analysis Phase
The Answer Is:
AExplanation:
The Value Methodology (VM) Job Plan consists of six phases, as outlined in the VMF 1 course (Core Competency #3: Value Methodology Job Plan). The phase dedicated to generating a large quantity of ideas or alternatives is the Creativity Phase (also known as the Creative Phase). According to SAVE International’s Value Methodology Standard, “the Creativity Phase is where a large quantity of ideas or alternatives is generated to accomplish the functions identified in the Function Analysis Phase, using techniques like brainstorming to encourage divergent thinking.” This phase focuses on producing as many ideas as possible without judgment, as established in Question 40, where the objective of the Creativity Phase was confirmed as generating improvement ideas.
Option A (Creativity Phase) is correct, as it is the phase dedicated to generating a large quantity of ideas to accomplish functions.
Option B (Presentation Phase) is incorrect because this phase involves presenting recommendations to stakeholders, not generating ideas.
Option C (Evaluation Phase) is incorrect because this phase involves assessing and selecting ideas, not generating them (as noted in Question 33).
Option D (Function Analysis Phase) is incorrect because this phase focuses on identifying and analyzing functions, not generating ideas (as noted in Question 37).
Which phase enables the VM team to select viable ideas?
Function Analysis
Presentation
Evaluation
Development
The Answer Is:
CExplanation:
The Value Methodology (VM) Job Plan, as outlined in the VMF 1 course and SAVE International’s Value Methodology Standard, consists of six phases, one of which is the Evaluation Phase, where the VM team selects viable ideas. In the Evaluation Phase, the team assesses ideas generated during the Creative Phase to determine their feasibility, cost impact, and alignment with project goals. According to the VMF 1 Core Competency #3 (Value Methodology Job Plan), the Evaluation Phase involves “evaluating the ideas for their potential to improve value, using criteria such as cost savings, performance, quality, and feasibility, to select the most viable alternatives for further development.” Tools like weighted evaluation matrices may be used to rank ideas systematically.
Option A (Function Analysis) is incorrect because this phase focuses on identifying and analyzing functions, not selecting ideas.
Option B (Presentation) is incorrect because this phase involves communicating recommendations to stakeholders, after ideas have already been selected and developed.
Option C (Evaluation) is correct, as it is the phase where the VM team filters and selects viable ideas based on defined criteria.
Option D (Development) is incorrect because this phase involves refining selected ideas into actionable proposals, which happens after the Evaluation Phase.
Which of the following are ground rules of the Creativity Phase? (Choose 3 answers)
Apply the "Principle of Deferred Judgment"
Establish an ambitious goal for the number of ideas
Emphasize cost savings
Encourage "Free-Wheeling" of ideas
Emphasize quality rather than quantity
The Answer Is:
A, B, DExplanation:
The Creativity Phase (also known as the Creative Phase) of the Value Methodology (VM) Job Plan focuses on generating a large quantity of ideas, as taught in the VMF 1 course (Core Competency #6: Creative Thinking and Idea Generation). According to SAVE International’s Value Methodology Standard, “the Creativity Phase follows ground rules to foster divergent thinking, including: applying the Principle of Deferred Judgment (no criticism of ideas), establishing an ambitious goal for the number of ideas (to maximize quantity), and encouraging ‘Free-Wheeling’ of ideas (welcoming wild or unconventional ideas).” These rules were partially addressed in Question 10, where ground rules like encouraging openness, freewheeling, and recording good ideas were confirmed, aligning with the focus on quantity over quality during this phase.
A. Apply the "Principle of Deferred Judgment": Correct, as this ensures no ideas are criticized during brainstorming, fostering creativity.
B. Establish an ambitious goal for the number of ideas: Correct, as setting a high target (e.g., 100 ideas) encourages the team to generate many ideas, focusing on quantity.
C. Emphasize cost savings: Incorrect, as cost savings are considered in the Evaluation and Development Phases, not during Creativity, where the focus is on idea generation without judgment.
D. Encourage "Free-Wheeling" of ideas: Correct, as freewheeling (allowing wild, unconventional ideas) is a standard brainstorming rule in VM to maximize creativity.
E. Emphasize quality rather than quantity: Incorrect, as the Creativity Phase prioritizes quantity over quality; quality is assessed later in the Evaluation Phase (as noted in Question 49).
The VM Job Plan provides a structured sequence of phases designed to leverage which of the following types of thinking?
Divergent and abstract
Convergent and abstract
Critical and divergent
Convergent and divergent
The Answer Is:
DExplanation:
The Value Methodology (VM) Job Plan, as outlined in the VMF 1 course (Core Competency #3: Value Methodology Job Plan), is a structured sequence of six phases designed to leverage bothdivergentandconvergentthinking. According to SAVE International’s Value Methodology Standard, “the VM Job Plan alternates between divergent thinking (to generate a wide range of ideas) and convergent thinking (to narrow down and refine those ideas).” Divergent thinking is used in the Creative Phase to brainstorm as many ideas as possible without judgment, while convergent thinking is applied in the Evaluation and Development Phases to analyze, select, and refine the best ideas into actionable proposals. This combination ensures a balance between creativity and practicality, maximizing value improvement.
Option A (Divergent and abstract) is incorrect because, while divergent thinking is used, “abstract” is not a specific type of thinking emphasized in the VM Job Plan.
Option B (Convergent and abstract) is incorrect because it omits divergent thinking, which is critical in the Creative Phase.
Option C (Critical and divergent) is incorrect because, while critical thinking is involved in Evaluation, the VM Job Plan specifically emphasizes convergent thinking to narrow down ideas.
Option D (Convergent and divergent) is correct, as it captures the dual thinking types leveraged across the VM Job Plan phases.
Which of the following is a basic function of a bicycle?
Transport Mass
Move People
Provide Transportation
Transport Goods
The Answer Is:
CExplanation:
Function Analysis in Value Methodology involves identifying and classifying functions using verb-noun combinations, as taught in the VMF 1 course (Core Competency #2). The basic function of an item is its primary purpose—what it must do to fulfill its intended use. For a bicycle, the basic function is the most general and essential action it performs. According to SAVE International’s Value Methodology Standard, functions should be defined in broad, measurable terms (e.g., verb-noun format) to capture the core purpose. The basic function of a bicycle is to “provide transportation,” as this encompasses its primary role of enabling movement for people or goods.
Option A (Transport Mass) is incorrect because “mass” is too vague and not specific to the bicycle’s purpose; it could apply to any object being moved.
Option B (Move People) is incorrect because, while a bicycle often moves people, this is a secondary function—bicycles can also transport goods (e.g., in cargo bikes), so it’s not the most fundamental function.
Option C (Provide Transportation) is correct because it captures the bicycle’s primary purpose in the broadest sense, covering both people and goods, aligning with VM’s focus on defining basic functions at a high level.
Option D (Transport Goods) is incorrect because transporting goods is a specific use case, not the bicycle’s primary function, which is broader.
The unique aspect of the value methodology is its application to anything that:
includes an activity.
performs a function.
is goal-oriented.
is a subject of study.
The Answer Is:
BExplanation:
Value Methodology (VM) is a versatile methodology, as taught in the VMF 1 course (Core Competency #1: Value Methodology Overview). According to SAVE International’s Value Methodology Standard, “the unique aspect of the Value Methodology is its focus on function analysis, making it applicable to anything that performs a function—whether a product, process, system, or service.” VM’s core principle is to improve value (function/cost) by analyzing what something does (its functions) and finding better ways to achieve those functions at lower cost without sacrificing performance. This focus on functions (e.g., “mark surface” for a pen, Question 38; “contain liquid” for a teacup, Question 44) allows VM to be applied universally to anything with a definable function, distinguishing it from other methodologies like Lean or Six Sigma, which focus on process efficiency or quality.
Option A (includes an activity) is incorrect because, while activities describe how functions are performed, VM’s unique aspect is its focus on functions, not activities.
Option B (performs a function) is correct, as VM’s defining feature is its application to anything with a function, per SAVE International’s standards.
Option C (is goal-oriented) is incorrect because many methodologies are goal-oriented; VM’s uniqueness lies in its function-based approach.
Option D (is a subject of study) is incorrect because being a subject of study is too broad; VM specifically targets subjects that perform functions.
Function E is the:
Secondary Function
Required Secondary Function
Basic Function
Higher Order Function
The Answer Is:
DExplanation:
The diagram provided is a Function Analysis System Technique (FAST) diagram, a key tool in Value Methodology’s Function Analysis phase, as taught in the VMF 1 course (Core Competency #2). FAST diagrams map the relationships between functions of a system, with the horizontal axis showing the “how-why” logic (critical path) and the vertical axis showing supporting functions. Functions are classified as basic, secondary, required secondary, or higher-order based on their position and role in the diagram. According to SAVE International’s Value Methodology Standard, “the basic function is the primary purpose of the system, typically found on the critical path; higher-order functions are the reasons why the basic function exists, located to the left of the basic function; secondary functions support the basic function and are often vertical; and required secondary functions are necessary to achieve the basic function.”
In the FAST diagram:
The critical path (horizontal, marked by Y in an earlier question) runs from E to F to G to J to L to M to N to O, representing the main sequence of functions.
Scope lines (B and D) define the study’s boundaries, as identified in Question 15.
Function E is positioned at the far left of the critical path, just inside the left scope line (B).
In FAST diagramming:
Thebasic functionis the primary purpose of the system, typically located near the center or right of the critical path within the scope lines. Here, it would likely be a function like J or L, which is central to the system’s purpose.
Thehigher-order functionis the reason “why” the basic function exists and is located to the left of the basic function, often at or near the left scope line. Function E, being the leftmost function on the critical path, answers “why” the subsequent functions (F, G, etc.) exist, making it the higher-order function.
Secondary functions(e.g., S, T, U, K) are vertical, supporting the critical path, and are not on the main horizontal sequence.
Required secondary functionsare secondary functions essential to the basic function, but E is on the critical path, not a vertical supporting function.
Thus, Function E, as the leftmost function on the critical path, is thehigher-order function, representing the overarching objective or need that the system fulfills.
Option A (Secondary Function) is incorrect because secondary functions are off the critical path (e.g., S, T, K), while E is on the critical path.
Option B (Required Secondary Function) is incorrect because E is not a secondary function; it is on the main path, not a supporting vertical function.
Option C (Basic Function) is incorrect because the basic function is typically more central on the critical path, not at the far left.
Option D (Higher Order Function) is correct, as E’s position at the left of the critical path indicates it is the higher-order function, answering “why” the system exists.
All-the-time functions are:
Outside the study scope
A drain on resources
Continuous
Undesirable
The Answer Is:
CExplanation:
In Value Methodology’s Function Analysis, functions are classified based on their characteristics, as taught in the VMF 1 course (Core Competency #2: Function Analysis). According to SAVE International’s Value Methodology Standard, “all-the-time functions are those that occur continuously or are always active during the operation of the system.” In a FAST diagram, all-the-time functions are often shown vertically (e.g., “when” direction) alongside the critical path, indicating they are ongoing while the main functions are performed. For example, in a car, “provide safety” (e.g., through seatbelts) is an all-the-time function because it is always active when the car is in use. This aligns with the FAST diagramming convention of showing simultaneous functions.
Option A (Outside the study scope) is incorrect because all-the-time functions are within the scope if they are part of the system’s operation, though they may be supporting functions.
Option B (A drain on resources) is incorrect because all-the-time functions are not necessarily resource-intensive; they are simply continuous.
Option C (Continuous) is correct, as it matches the definition of all-the-time functions in VM.
Option D (Undesirable) is incorrect because all-the-time functions are not inherently undesirable; they may be essential (e.g., “provide safety”).
Which of the following best defines an activity?
A task, action, or operation that describes why a function is performed
A specific task, action, or operation that is generic and changes viewpoints
A task, action, or operation that describes how a function is performed
A specific task, action, or operation with a high level of abstraction
The Answer Is:
CExplanation:
In Value Methodology’s Function Analysis, the concepts of functions and activities are distinct but related, as taught in the VMF 1 course (Core Competency #2: Function Analysis). According to SAVE International’s Value Methodology Standard, “a function is defined as what a product, process, or system does, expressed in a verb-noun format (e.g., ‘contain liquid’), while an activity is a task, action, or operation that describes how a function is performed.” For example, the function of a teacup might be “contain liquid,” and the activity to achieve that function could be “holding the liquid in a ceramic structure.” Activities are the actionable steps or processes that enable the function, often identified during the creation of a FAST diagram or Random Function Identification table (as noted in Question 19). The “how” aspect aligns with the How-Why logic of FAST diagrams, where activities detail the practical execution of a function.
Option A (A task, action, or operation that describes why a function is performed) is incorrect because “why” relates to the higher-order function or purpose (e.g., Question 20), not the activity, which focuses on “how.”
Option B (A specific task, action, or operation that is generic and changes viewpoints) is incorrect because activities are not about changing viewpoints; they are specific actions to perform a function.
Option C (A task, action, or operation that describes how a function is performed) is correct, as it aligns with the definition of an activity in VM.
Option D (A specific task, action, or operation with a high level of abstraction) is incorrect because activities are practical and specific, not abstract; functions are more abstract (e.g., verb-noun format).
