Free Practice Questions for Nokia 4A0-220 Exam

In a 1830PSS MRN network, groups of links can be combined (bundled) together in a single TE-Link both within layer 0 and 1 networks. A TE-Link is a logical representation of one or more physical links that share the same attributes and can be used to establish Label Switched Paths (LSPs). A TE-Link can be either single-layer or multi-layer, depending on the switching capabilities of the links. In a single-layer TE-Link, all the links belong to the same layer, either layer 0 (optical) or layer 1 (OTN). In a multi-layer TE-Link, the links belong to different layers, such as layer 0 and layer 1. A TE-Link can be either bundled or unbundled, depending on the number of links it contains. A bundled TE-Link contains more than one link, while an unbundled TE-Link contains only one link. A bundled TE-Link can provide more bandwidth and flexibility than an unbundled TE-Link. References : Nokia GMPLS-controlled Optical Networks Course | Nokia, 3. GMPLS - Nokia

Preemption is a mechanism that allows a higher priority LSP to tear down an existing lower priority LSP in order to obtain the required resources for its establishment. Preemption can occur when there is not enough bandwidth or other resources available on a link or node to accommodate a new LSP request. In this case, the node can select one or more lower priority LSPs that are using the resources and send them a PathErr message with a Preempt error code. This causes the lower priority LSPs to beterminated and release their resources. The node can then allocate the resources to the higher priority LSP and send a Resv message to confirm its reservation34. References:

3: RFC 4829: Label Switched Path (LSP) Preemption Policies for MPLS Traffic Engineering4

4: MPLS Applications User Guide | Juniper Networks5

To configure the Trail template in NFM-T for an Uplink board (such as 2UC400) in a network with only LI restoration capability, you need to check the Logical Link box, set the Port Type to Unterminated, uncheck the ASON Routed box, and uncheck the ASON Tunnel box. This configuration allows you to create a logical link between two Uplink boards that can be used for LI restoration. The logical link is not terminated at the Uplink board, but at the OTU board. The ASON Routed option is not needed for LI restoration, as the LSPs are established by NFM-T and not by GMPLS. The ASON Tunnel option is not applicable for Uplink boards. References : Nokia Advanced Optical Network Management with NFM-T Course | Nokia, Nokia 1830 PSS-4, PSS-8, PSS-16 and PSS-32 Platforms - NATO

The Feasibility File is a file that contains a set of target values for various optical impairment parameters, such as OSNR, CD, PMD, and PDL, that are used to determine whether a given LSP can be routed through the GMRE network. The Feasibility File is generated by the Network Planning Application (NPA) based on the network design and the service requirements. The Feasibility File is then loaded into the GMRE nodes and used by the GMPLS routing engine to perform feasibility checks for LSP requests. The Feasibility File ensures that the LSPs are routed in accordance with the network plan and the optical performance criteria12. References:

1: Nokia GMPLS-controlled Optical Networks Course | Nokia

2: GMPLS - Nokia

The GMRE functionality is guaranteed in Nokia equipment by controller redundancy. The controller is the hardware component that runs the GMPLS software and controls the switching fabric of the node. Each node has two controllers, one active and one standby, that synchronize their states and databases. If the active controller fails, the standby controller takes over and ensures the continuity of the GMRE functionality. References : Nokia GMPLS-controlled Optical Networks Course | Nokia, 1830 Photonic Service Switch (PSS) | Nokia

RSVP-TE Notify message is a message type defined in the RSVP-TE protocol, which is an extension of the RSVP protocol for MPLS traffic engineering. RSVP-TE Notify message is used to inform non-adjacent nodes of LSP events, such as setup, modification, or teardown. This allows the nodes to update their local state information and perform actions based on the notification. For example, a Notify message can be used to trigger a fast reroute mechanism in case of a link or node failure12. References:

1: RFC 3473 - Generalized Multi-Protocol Label Switching (GMPLS) Signaling Resource Reservation Protocol-Traffic Engineering (RSVP-TE) Extensions

2: RFC 3471 - Generalized Multi-Protocol Label Switching (GMPLS) Signaling Functional Description

A Label Switched Path (LSP) is the path created by MPLS nodes that use labels to forward packets across the network. A label is a short identifier that is attached to each packet and indicates the next hop or destination of the packet. The nodes use a label forwarding table to switch packets based on their labels, without inspecting the packet headers. This can improve the performance, security, and quality of service of the network. An LSP can be established by using GMPLS protocols such as OSPF-TE and RSVP-TE, which exchange information about the network topology, resources, and constraints. References : Nokia GMPLS-controlled Optical Networks Course | Nokia, GMPLS - Nokia

GMPLS is a protocol suite that extends the MPLS signaling and routing capabilities to control different types of switching technologies, such as optical, TDM, and packet switching1. GMPLS has several key features, such as self-discovery, fast protection, and restoration. Self-discovery allows GMPLS nodes to automatically discover their neighbors and exchange information about their capabilities and resources2. Fast protection enables GMPLS nodes to quickly switch to backup paths in case of a failure, without relying on the control plane3. Restoration allows GMPLS nodes to dynamically establish new paths in the network after a failure, using the control plane3. Resource optimization is not a key feature of GMPLS, but rather a potential benefit of using GMPLS to efficiently utilize the network resources and avoid over-provisioning. References:

1: Nokia GMPLS-controlled Optical Networks Course | Nokia

2: GMPLS - Nokia

3: Traffic survivability through Protection and Restoration Combined (PRC) - YouTube

[4]: GMPLS: Architecture and Applications - Google Books

Quality of Service (QoS) in GMPLS is the ability to set constraints such as latency and priority for different kinds of services. This means that GMPLS can allocate network resources according to the specific requirements of each service, such as voice, video, or data. For example, a voice service may need low latency and high priority, while a data service may need high bandwidth and low priority. GMPLS can use Traffic Engineering (TE) extensions to OSPF and RSVP protocols to advertise and reserve network resources based on QoS parameters. References : [Nokia GMPLS-controlled Optical Networks Course | Nokia], [Quality of Service - Nokia]
