Click on the exhibit.

The numbers beside the links are the metrics for that link.

Given the diagram, what path will traffic follow from router R1 to router R7, and from router R7 to router R1, if IS-IS is the routing protocol?

A.

Router R1 to router R7 will follow (R1-R2-R4-R6-R7). Router R7 to R1 will follow (R7-R6-R4-R2-R1)

B.

Router R1 to router R7 will follow (R1-R2-R4-R6-R7). Router R7 to R1 will follow (R7-R6-R5-R3-R1)

C.

Router R1 to router R7 will follow (R1-R3-R5-R6-R7). Router R7 to R1 will follow (R7-R6-R4-R2-R1)

D.

Router R1 to router R7 will follow (R1-R3-R5-R6-R7). Router R7 to R1 will follow (R7-R6-R5-R3-R1)

To configure 6over4 tunneling, where must indirect static routes be configured?

A.

On the CEs only.

B.

On the PEs only.

C.

On only the branch office CE.

D.

On both the CEs and PEs.

Click on the exhibit.

The route table on router R2 shows the system address of router R5 but it does not show any of the interfaces from the non-OSPF area.

What may be causing this?

A.

'asbr' is missing from router R1's configuration.

B.

Router R1 needs to have an export policy added to it.

C.

Router R5 does not have an export policy for these prefixes.

D.

Router R1 needs to have an import policy added to it.

Click on the exhibit.

Examine the physical topology of the IS-IS network, the metrics of the links and the levels of the routers. All routers have a system address included in IS-IS.

Which of the following describes the route that router R4 will use to reach the system address of router R6?

A.

Router R4 will have a route to router R6's system address with router R2 as the next-hop.

B.

Router R4 will have a default route with router R2 as the next-hop.

C.

Router R4 will have a default route with router R3 as the next-hop.

D.

Router R4 will not have a route that can be used to reach the system address of router R6.
