Free Practice Questions for Nokia 4A0-100 Exam

In Nokia SR OS:

Aphysical interfacerefers to a physical port on the router (e.g., port 1/1/1).

It can be configured withIP addresses, associated with services (e.g., IES, VPRN), and connects to other routers or customer devices.

Systemandloopbackinterfaces arelogical interfaces, not physical.

Option D is FALSE, because a physical interfacecannotbe of type "system" or "loopback" — those arevirtual/logicalinterfaces in the Nokia router architecture.

ICMP (Internet Control Message Protocol)is used for network diagnostics and error messaging. Key uses include:

Ping (Echo Request/Reply)– tests end-to-end connectivity✔

Traceroute– uses ICMP time exceeded messages to identify hops✔

Error reporting– returns various error types with differentcodes✔

However,ICMP does not re-route traffic. If a destination is unreachable, ICMP reports the error back to the sender; it doesn’t instruct routers to re-route.

Option D is FALSE– ICMPdoes not perform routing.

Tier 1 ISPs: Haveglobal reachabilityand exchange traffic via peering. Theydo not payfor transit.

Tier 2 ISPs: Purchasetransit services from Tier 1and provide transit to Tier 3 or other Tier 2 ISPs.

Tier 3 ISPs: Providelast-mileconnectivity to end users and donot provide transit services.

Option A is correct– Tier 1 and Tier 2provide transit services.

Link-State routing protocols(e.g.,OSPF,IS-IS) operate by:

Each routerflooding link-state advertisements (LSAs)throughout the network.

Every router constructs acomplete map of the network topology.

Then each router runs theSPF algorithmto compute optimal paths.

Option C is correct– routers know theentire network topology.

Option A isDistance Vector behavior(e.g., RIP).

Option B isnot efficient or accurate for Link-State.

Option D –hop-countis used inDistance Vector(e.g., RIP).

AVPRN (Virtual Private Routed Network)provides aLayer 3 VPN serviceover a service provider’s network.

Each customer site connects to aPE router.

Sites are connected via arouted networkusingseparate routing instances.

Customer routers seerouted connectivity, as if connected to their own private WAN.

Option C is correct– VPRN providesrouted connectivitybetween sites.

AMAC address(Media Access Control address) is a 48-bit identifier typically expressed in six groups of two hexadecimal digits (e.g., 00-20-60-CE-2B-28). It consists of two key parts:

OUI (Organizationally Unique Identifier)– The first24 bits(or first 3 octets, e.g., 00-20-60) are assigned by theIEEE to hardware manufacturers. This identifies the vendor or manufacturer.

Device Identifier (NIC Specific)– The remaining24 bits(e.g., CE-2B-28) are assigned uniquely by the vendor to each device/interface.

So in the address 00-20-60-CE-2B-28:

00-20-60 is theOUI

CE-2B-28 is thedevice-specific portion

Thus, the correct answer isD. 00-20-60.

When a routerforwards a packet, it performs the following operations:

Looks up the destination IP addressin therouting tableto determine thenext hoporegress interface.

Uses theARP tableto resolve theMAC address of the next-hop IP.

Option Ais incorrect – source IP is not used for route lookup.

Option Cis incorrect – routers don’t resolve thesource MAC.

Option Dis partially true, butrouting begins with the routing table, makingBthe most accurate.

VPWS (Virtual Private Wire Service)on Nokia 7750 SR:

Emulates aLayer 2 point-to-pointconnection.

Does not require MAC learning, unlike VPLS.

UsesMPLS encapsulation,not IP datagramsfor transport.

Option D is FALSE– VPWS usesMPLS labels, not IP encapsulation.

TheModel-Driven Command Line Interface (MD-CLI)in Nokia SR OS provides a structured and programmatic way to manage configurations. It is based on atransactional model, meaning changes are made in a candidate configuration before being committed to the running configuration.

Let's review each statement:

A. It allows atomic transactions–✔True. MD-CLI uses atomic transactions to apply multiple changes at once, ensuring consistency and rollback if a failure occurs.

B. Configuration changes are activated when the running configuration datastore is saved to a file–❌False. In MD-CLI, changes are committed to therunning datastorewhen a user issues the commit command,not when saving to a file. Saving to a file is a separate action (e.g., admin save) and doesnot trigger configuration activation.

C. To achieve transactional configuration, it is necessary to have multiple configuration datastores–✔True. MD-CLI usescandidate,running, andoperationaldatastores to implement transaction-based configuration.

D. Multiple users may enter the global configuration mode concurrently–✔True. MD-CLI supportsmulti-user accessto global configuration with locking mechanisms to prevent conflicts.
