Free Practice Questions for CompTIA SY0-701 Exam

A diagram of a computer AI-generated content may be incorrect.

Step 1: Understand Requirements & Security Principles

Requirements:

Customer-facing payment application (PCI DSS compliance applies)

Hosted on third-party cloud (e.g., AWS)

Must segment public-facing and internal resources

Needs to be scalable and resilient

Must have strong security controls

Step 2: Design the High-Level Network Layout

Core Components:

VPC (Virtual Private Cloud): Isolates your environment from other tenants in the cloud.

Subnets:

Public subnet: For resources that must communicate with the internet.

Private subnet: For internal resources, NOT directly exposed to the internet.

Step 3: Place Resources in Appropriate Subnets

Public Subnet:

Internet-facing Load Balancer (LB): Distributes traffic to application servers.

Web Application Firewall (WAF): Protects against web exploits.

Autoscaling Instances: EC2 (or VM) servers running your web front-end, automatically scaling as traffic grows.

Private Subnet:

Application servers: Back-end logic, not exposed to internet directly.

Database: Sensitive data storage, only accessible by application servers.

Internal Load Balancer: Manages traffic among app servers.

WAF: Can be used internally as well for defense-in-depth.

Step 4: Add Connectivity and Security Controls

Internet Gateway: Allows resources in public subnet to communicate with the internet.

NAT Gateway: Allows outbound internet traffic from private subnet without exposing private IPs.

Security Groups: Firewalls at the instance level; allow only necessary traffic (e.g., LB to web server, web server to DB).

Network ACLs: Subnet-level firewalls for additional control.

Step 5: Network Diagram Explanation (Based on Your Images)

Public Subnet (Top Layer)

Load Balancer

Accepts HTTPS traffic from customers.

Sends only necessary HTTP/HTTPS to web servers in public subnet.

WAF (Web Application Firewall)

Sits in front of Load Balancer.

Filters malicious requests (SQLi, XSS, etc.).

Autoscaling Group

Multiple web servers for redundancy and scalability.

Placed in public subnet to respond to traffic spikes.

Private Subnet (Bottom Layer)

Application Servers

Receive requests from public subnet’s load balancer.

Not directly exposed to the internet.

Database

Only accessible from application servers, never public.

Security groups restrict all inbound traffic except from app servers.

Internal Load Balancer

Balances requests to application servers.

Step 6: Flow of Data (Step-by-Step)

Client -> Internet Gateway -> WAF -> Load Balancer (Public Subnet):Customers initiate connections to your app over the internet.

Load Balancer -> Autoscaling Web Servers (Public Subnet):Load balancer routes requests to available web servers.

Web Servers -> Application Logic (Private Subnet):Web servers pass necessary requests to the internal application servers.

App Servers -> Database (Private Subnet):Application servers query/update customer payment data in the database.

Outbound (NAT Gateway):App servers may need to access updates or external APIs—use NAT Gateway for secure outbound connections.

Step 7: Security Best Practices

Security Groups: Only allow necessary ports (e.g., 443 for HTTPS to LB, 3306 for MySQL between app server and DB).

Network ACLs: Add another layer of subnet-level restrictions.

Encryption: Use HTTPS for all external connections, encrypt data at rest and in transit (TLS, disk encryption).

IAM Roles/Policies: Principle of least privilege for accessing resources.

Monitoring/Logging: Enable VPC flow logs, cloud service logs, and application logging.

Patch Management: Automate patching for OS and applications.

Backups: Regular, secure backups of critical data.

Step 8: Compliance Considerations

For payment applications (PCI DSS):

Isolate cardholder data environment (CDE).

Strong access controls (multi-factor authentication, role separation).

Regular vulnerability assessments and penetration testing.

Retain logs for auditing.

Step 9: Draw the Architecture (Summary)

Internet Gateway: Allows inbound/outbound internet access.

Public Subnet: WAF, Load Balancer, Autoscaling group.

Private Subnet: App servers, DB, internal LB.

NAT Gateway: Outbound access for private resources.

Security Groups/ACLs: Control all traffic flows.

Monitoring/Logging: Enabled at all levels.

Bonus: Sample Security Group Rules

Web Server (Public Subnet):

Inbound: 443 (HTTPS) from Internet

Outbound: 80/443 to App Servers

App Server (Private Subnet):

Inbound: 80/443 from Web Servers

Outbound: 3306 (MySQL) to Database

Database (Private Subnet):

Inbound: 3306 from App Servers

Outbound: None (unless replication required)

References to Security+ Domains

1.0 General Security Concepts: Principle of least privilege, defense in depth.

2.0 Threats, Vulnerabilities, Mitigations: WAF, segmentation, patching.

3.0 Security Architecture: Network segmentation, secure design.

4.0 Security Operations: Monitoring, logging, response.

5.0 Security Program Management: Compliance, policy.

E-discovery (electronic discovery) is the process of identifying, collecting, and producing electronically stored information (ESI) in response to a legal request or investigation. It is a critical component of digital forensics when dealing with litigation, compliance, or regulatory matters.

Packet capture data can be very large and may not need to be stored for extended periods compared to other logs essential for security audits.

=================

Hashing produces a fixed-length fingerprint of the script’s contents. By comparing the current hash with a known good hash, the engineer can verify if the script has been altered. Hashing is a one-way function used to validate integrity.

Masking (A) hides data, obfuscation (B) hides code logic, and encryption (D) protects confidentiality but does not verify integrity as simply.

Integrity checking through hashing is fundamental in General Security Concepts【6:Chapter 7†CompTIA Security+ Study Guide】.

A qualitative risk analysis assigns descriptive ratings such as high, medium, or low to risks based on their likelihood and impact without numerical calculations.

Including MTTR/MTBF (A) and ALE/ARO (D) are quantitative methods using metrics. Risk registers (B) document risks but don’t specify analysis type.

Qualitative and quantitative risk methods are fundamental in SY0-701 risk management【6:Chapter 17†CompTIA Security+ Study Guide】.

The log entries show repeated attempts to access directories using patterns such as ../, which is a common directory traversal attack technique. Directory traversal (or path traversal) aims to access files and directories outside the web server's root directory by manipulating file paths. The ../ sequence is used to move up one directory level, which attackers exploit to try and retrieve sensitive files.

Detailed Explanation:The activity described in the table, where multiple connection attempts are made on port 445 (used for SMB services), suggests a brute-force attack. The attacker likely used automated methods to guess credentials, causing multiple failures. Such attempts are ahallmark of brute-force attacks targeting shared resources. Reference: CompTIA Security+ SY0-701 Study Guide, Domain 4: Security Operations, Section: "Indicators of Malicious Activity"​​.

A physical security control is a device or mechanism that prevents unauthorized access to a physical location or asset. An access control vestibule, also known as a mantrap, is a physical security control that consists of a small space with two sets of interlocking doors, such that the first set of doors must close before the second set opens. This prevents unauthorized individuals from following authorized individuals into the facility, a practice known as piggybacking or tailgating. A photo ID check is another form of physical security control that verifies the identity of visitors. Managerial, technical, and operational security controls are not directly related to physical access, but rather to policies, procedures, systems, and processes that support security objectives. References: CompTIA Security+ Study Guide: Exam SY0-701, 9th Edition, page 341; Mantrap (access control) - Wikipedia2

The document described in the question is a Disaster Recovery Plan (DRP). A DRP outlines the process and procedures for restoring critical systems and operations after a major disruption or outage. It includes the order in which systems should be brought back online to ensure minimal impact on business operations, prioritizing the most critical systems to recover first.

 Analysis is the incident response activity that describes the process of understanding the source of an incident. Analysis involves collecting and examining evidence, identifying the root cause, determining the scope and impact, and assessing the threat actor’s motives and capabilities. Analysis helps the incident response team to formulate an appropriate response strategy, as well as to prevent or mitigate future incidents. Analysis is usually performed after detection and before containment, eradication, recovery, and lessons learned. References = CompTIA Security+ Study Guide with over 500 Practice Test Questions: Exam SY0-701, 9th Edition, Chapter 6, page 223. CompTIA Security+ SY0-701 Exam Objectives, Domain 4.2, page 13.

Anair-gapped (C)system is completely isolated from unsecured networks (like the internet) and other systems, preventing any form of remote access. This is often used in highly sensitive environments such as military, nuclear, or critical infrastructure systems.

This is mentioned underDomain 3.4: Given a scenario, apply cybersecurity resilience conceptsin theCompTIA Security+ SY0-701 Exam Objectives, specifically under“Isolation (e.g., air-gapped)”.

ARP poisoning(also known as ARP spoofing) is a basicman-in-the-middle (MITM)attack that involves sending fake ARP responses to redirect traffic. This technique isnot sophisticatedand can be easily executed using freely available tools like Cain & Abel, Ettercap, or Wireshark.

Such attacks are often attempted byunskilled attackers (script kiddies)testing their abilities, especially in environments like schools. The term“unskilled attacker”fits best here, as credential stuffing and DMARC are unrelated to ARP poisoning.

According to the shared responsibility model, the client and the cloud provider have different roles and responsibilities for securing the cloud environment, depending on the service model. In an IaaS (Infrastructure as a Service) model, the cloud provider is responsible for securing the physical infrastructure, such as the servers, storage, and network devices, while the client is responsible for securing the operating systems, applications, and data that run on the cloud infrastructure. Therefore, the client is responsible for securing the company’s database in an IaaS model for a cloud environment, as the database is an application that stores data. The client can use various security controls, such as encryption, access control, backup, and auditing, to protect the database from unauthorized access, modification, or loss. The third-party vendor and the DBA (Database Administrator) are not roles defined by the shared responsibility model, but they may be involved in the implementation or management of the database security. References = CompTIA Security+ SY0-701 Certification Study Guide, page 263-264; Professor Messer’s CompTIA SY0-701 Security+ Training Course, video 3.1 - Cloud and Virtualization, 5:00 - 7:40.

The scenario suggests that only the employees who used the kiosks inside the building had their credentials compromised. Since the time-keeping website is accessible from the internet, it is possible that a malicious actor exploited an unpatched vulnerability in the site, allowing them to inject malicious code that captured the credentials of those who logged in from the kiosks. This is a common attack vector for stealing credentials from web applications.

References =

CompTIA Security+ SY0-701 Course Content: The course discusses web application vulnerabilities and how attackers can exploit them to steal credentials​​.
