Free Practice Questions for CompTIA 220-1201 Exam

A workstation running three high-end GPUs requires a power supply capable of both high wattage and stable, reliable output. In CompTIA A+ power supply fundamentals, modularity and redundancy are emphasized for high-performance and mission-critical systems.

Modularity (B) allows the technician to connect only the necessary cables, reducing clutter, improving airflow, and enabling proper cable routing to multiple GPUs. High-end graphics cards require multiple PCIe connectors, and modular PSUs provide the flexibility to attach the exact number of required GPU power cables. This is important for systems where space management and cooling efficiency directly affect performance and component longevity.

Redundancy (D) is critical for mission-critical workstations used for 3-D modeling and rendering. A redundant power supply ensures that if one PSU module fails, the system continues running without interruption. CompTIA A+ highlights redundancy as a key feature in professional environments where uptime is essential. These systems typically use dual hot-swappable power modules to guarantee continuous power delivery.

The other options do not meaningfully address the requirements. A 12V output is standard on all PSUs. A 20-pin connector is outdated; modern motherboards use 24-pin. The 3.3V rail is not relevant to GPU loads, and 240 VAC input only refers to wall power compatibility, not PSU capability. Therefore, modularity and redundancy best meet the workstation’s needs.

Power over Ethernet (PoE) is specifically designed to power network devices without requiring a separate electrical outlet. According to CompTIA Core 1 (220-1201) networking hardware objectives, PoE allows both data and electrical power to be delivered over a single Ethernet cable from a PoE-capable switch or injector to the connected device.

PoE is commonly used for devices such as wireless access points, IP cameras, VoIP phones, and access control systems, especially in locations where installing electrical outlets is difficult, expensive, or impractical. This makes PoE an ideal solution for flexible and scalable network deployments.

WWAN (Wireless Wide Area Network) provides cellular-based network connectivity but does not supply power to devices. An ONT (Optical Network Terminal) converts fiber signals to Ethernet and requires its own power source. NFC (Near Field Communication) is a short-range wireless technology used for authentication and data exchange, not for powering network devices.

CompTIA highlights PoE as a key networking technology that simplifies installations by reducing cabling requirements and eliminating the need for local power outlets.

The requirements describe an environment transitioning gradually from on-site hardware to scalable cloud services. The business wishes to continue using its existing local equipment until end of life, while also expanding computing resources beyond what the on-premises infrastructure can handle. Additionally, the cloud environment must be able to share data with the internal data center.

This aligns perfectly with a hybrid cloud model, which CompTIA A+ defines as a combination of private (on-premises) and public cloud resources operating together. Hybrid cloud enables secure data sharing, workload distribution, and scaling without eliminating existing hardware investments. It allows organizations to offload high-demand processes to the cloud while maintaining sensitive data or critical services on-site.

A private cloud (D) would not allow scaling into a public provider efficiently. A public cloud (A) replaces internal resources instead of complementing them. A community cloud (B) is shared among organizations with similar compliance requirements—not applicable here. SaaS (E) refers to hosted applications, not infrastructure scalability.

Thus, a Hybrid cloud model fulfills all stated requirements: seamless data sharing, scalable computing, and continued use of on-site equipment.

Quality of Service (QoS) prioritizes VoIP traffic on the network, reducing jitter, latency, and packet loss to improve call quality.

From CompTIA A+ 220-1101 Official Study Guide, Objective 2.4 – Network troubleshooting:

“Enabling QoS in the router ensures time-sensitive traffic, like VoIP, receives network priority, reducing dropped or lagging calls.”

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 2: Network Troubleshooting

CompTIA Exam Objectives 220-1101, Domain 2.4

============

RAID 5 provides fault tolerance by distributing parity information across all drives, allowing the array to continue operating if one drive fails. In a three-drive RAID 5 set, a single disk failure puts the array into a degraded state where it can still function, but it is at higher risk because losing a second drive before recovery would cause data loss. Since the system reports Drive 3 has failed after a power outage, the best next step to minimize risk is to replace the failed drive immediately and start the rebuild. Rebuilding regenerates the missing data blocks onto the new drive using parity, returning the array to a protected state.

Option B leaves the array degraded and increases exposure to a second failure. Option C (firmware upgrade) is not a first response in an active failure scenario and can introduce additional risk or downtime. Option D (restore from backup) is typically used when the array is unrecoverable or multiple drives fail; it is more disruptive and unnecessary when RAID 5 can recover from a single-disk failure. Therefore, replacing the defective drive and triggering an array rebuild is the correct next step.

To allow multiple users to print to networked printers:

Printer shares enable users to access printers shared on the network.

Print servers manage print jobs and provide centralized control of printing.

Why Not B (DHCP server): DHCP is unrelated to print management.

Why Not D (Printer subnet): Subnets group devices but don’t manage printing.

Why Not E (SMB configuration): SMB is for file sharing, not specifically print management.

Why Not F (Printer Wi-Fi settings): These settings are irrelevant since the printers use Ethernet.

CompTIA A+ Exam Reference: Core 2 (220-1102), Section 4.6, printer configuration​.

If newly installed RAM is not fully recognized, the most likely cause is incorrect installation or incompatible slots. Reseating or reinstalling the RAM modules in the correct slots can quickly resolve the issue without extra cost.

From CompTIA A+ 220-1101 Official Study Guide, Objective 3.2 – Install and configure PC components:

" If memory is not detected, check installation and reseat modules. Ensure they are placed in the correct, matched slots for dual-channel operation. "

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 3: Memory Installation

CompTIA Exam Objectives 220-1101, Domain 3.2

============

C. Installing redundant PSUs (Power Supply Units):

Redundant PSUs provide fault tolerance by ensuring that if one power supply fails, another will take over seamlessly.

This is a cost-effective way to increase uptime while waiting for the UPSs to arrive.

Incorrect Options:

A. Purchasing backup generators: Generators are costly and are typically used for long-term outages, not as an immediate or cost-effective solution.

B. Increasing input voltage: This is not a practical solution to hardware failures or power issues.

D. Activating a hot site: A hot site is an expensive, fully operational backup facility that would not be a cost-effective solution for this scenario.

Key Takeaway: Installing redundant PSUs is a cost-effective way to balance uptime requirements in case of power or hardware failure.

Comprehensive and Detailed Step-by-Step Explanation:

Modifying duplex settings to double-sided:

Printing on both sides of the paper (duplex printing) reduces paper usage, making it one of the most effective environmentally friendly printing initiatives.

It directly minimizes waste and supports sustainability goals in the workplace.

Incorrect Options:

A. Requiring user authentication for printing: While this can reduce unnecessary or unauthorized printing, it does not directly address environmental objectives like saving resources.

B. Locking down printing to only certain individuals: Limiting access may reduce printing overall, but it does not actively contribute to environmentally friendly practices like duplex printing.

D. Changing the print quality settings to best: Using the " best " print quality increases toner or ink usage, which is counterproductive to environmentally friendly objectives.

Key Takeaway:

Modifying duplex settings to enable double-sided printing is the best initiative to achieve environmentally friendly goals by reducing paper consumption.
