Free Practice Questions for CompTIA 220-1201 Exam

Inkjet printers are the best choice for a small company seeking full-color printing with a minimal initial cost. While they have higher operating costs (due to ink), they are affordable and capable of high-quality color output.

Why Not A (Thermal printer): Thermal printers are not designed for color printing and are typically used for labels or receipts.

Why Not C (Dot matrix printer): Dot matrix printers are outdated, noisy, and do not support full-color printing.

Why Not D (Laser printer): Laser printers have lower running costs but a higher initial purchase price, especially for color models.

CompTIA A+ Exam Reference: Core 2 (220-1102), Section 4.6, printer types​.

A hard disk drive (HDD), especially if it ' s older or nearly full, is the most common cause of slow startup times in laptops. HDDs are much slower than SSDs and can significantly bottleneck the boot process.

From CompTIA A+ 220-1101 Official Study Guide, Objective 4.1 – Troubleshoot common hardware problems:

“A slow startup or sluggish system performance is commonly due to a failing or fragmented hard disk drive (HDD). Replacing with an SSD can greatly improve boot times and overall system responsiveness.”

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 4: Troubleshooting PC Hardware

CompTIA Exam Objectives 220-1101, Domain 4.1

============

A firewall implements ACLs (Access Control Lists) to filter traffic and enforce policies based on rules such as IP address, port, or protocol.

Why Not A (Managed switch): A managed switch supports VLANs and QoS but does not enforce ACLs at the network perimeter.

Why Not B (Gateway): Gateways connect networks and translate protocols but don’t typically implement ACLs.

Why Not C (Repeater): Repeaters extend signal range but don’t enforce policies.

CompTIA A+ Exam Reference: Core 1 (220-1201), Section 2.2, firewall concepts​.

Comprehensive and Detailed Explanation From Exact Extract (Aligned With CompTIA A+ 220-1201 Study Guide)

CompTIA networking fundamentals describe VLANs (Virtual Local Area Networks) as a method to segment network traffic logically, even while using the same physical switch hardware.

A VLAN allows a company to:

Separate traffic by department

Improve security

Reduce broadcast domains

Control inter-department access

To separate accounting and customer service networks, VLANs are the industry-standard and the CompTIA-approved method.

Why the other options are incorrect

A. VPN – Used for secure remote connections, not internal LAN segmentation.

B. DNS – Resolves hostnames to IPs, not used for network separation.

D. DHCP – Assigns IP addresses; does not isolate network groups.

Final Answer: C

Reasoning: A docking station is designed to provide a central connection point for multiple peripherals, such as monitors, keyboards, mice, and network cables. It allows users to quickly connect or disconnect all devices by simply docking or undocking their laptop, improving mobility and reducing wear and tear on individual ports.

Why the Other Options Are Incorrect:

A. Serial interfaces:

Serial interfaces are outdated and rarely used in modern laptops or peripherals. They are not practical for facilitating the connection of multiple devices.

C. Network switch:

A network switch is used to connect multiple devices to a network, but it does not simplify the connection of peripherals to a laptop.

D. USB hub:

A USB hub can extend the number of available USB ports but lacks the full functionality of a docking station, such as video output or Ethernet connectivity.

Practical Example:

A user with a laptop, external monitors, keyboard, and mouse can use a docking station to connect all devices with a single action, instead of plugging in each device manually.

CompTIA A+ Exam Objective Alignment:

Objective 5.2: Explain device interfaces, connection types, and usage of docking stations.

Comprehensive and Detailed Step-by-Step Explanation:

S.M.A.R.T. (Self-Monitoring, Analysis, and Reporting Technology):

S.M.A.R.T. is a monitoring system integrated into modern HDDs and SSDs that detects and reports on various indicators of drive health and reliability.

A S.M.A.R.T. error indicates that the drive is showing signs of impending failure, even if the PC continues to boot and work normally for the time being.

Next Steps:

The appropriate action is to replace the hard drive (HDD) because a S.M.A.R.T. error is an early warning of possible hardware failure. Ignoring the warning could result in data loss if the drive fails completely.

The technician should also back up the user ' s data immediately to avoid losing critical information.

Incorrect Options:

B. Update the PC ' s BIOS: While keeping the BIOS updated is a good practice, it does not address the S.M.A.R.T. error, which is specific to the HDD.

C. Close the ticket: Closing the ticket without resolving the issue would be improper, as the S.M.A.R.T. error is a hardware problem that needs to be addressed to prevent future data loss or downtime.

D. Change the NIC: The NIC (Network Interface Card) is unrelated to the storage system and would not resolve a S.M.A.R.T. error.

Key Takeaway:

A S.M.A.R.T. error is a critical indicator of HDD health issues, and the drive should be replaced as soon as possible. Backing up data is also essential.

When a printer refuses to use paper that is physically present in the tray, CompTIA A+ identifies tray configuration settings as the most likely cause. Printers require a match between tray settings (paper size, paper type, orientation) and the incoming print job’s specifications. If the tray is incorrectly configured—such as being set to Letter (8.5×11 in) or A4—then the printer will keep prompting for the correct paper even though 11×17 paper is loaded.

The fact that the technician successfully prints the same diagram on another identical printer proves that the driver, print job format, and user permissions are correct. This isolates the issue to the local printer’s configuration. Incorrect drivers (B) would affect printing on both printers. Connectivity issues (C) would prevent printing entirely, not cause paper prompts. Permissions (D) do not affect paper-size recognition.

Therefore, the most likely cause is improper tray settings on the user’s printer.

The most effective solution to resolve this issue and prevent it from happening again is to assign the printer a static IP address. According to CompTIA Core 1 (220-1201) networking and printer configuration objectives, network printers should use static IP addresses to ensure consistent accessibility by client devices.

In this scenario, the printer was initially reachable using its assigned network address, but after several days it became unavailable. This commonly occurs when the printer is configured to receive its IP address via DHCP. When the DHCP lease expires or the printer is rebooted, the router may assign a different IP address, causing all workstations configured with the old address to lose connectivity.

By configuring a static IP address (or DHCP reservation), the printer’s IP address remains constant, ensuring that all workstations can reliably send print jobs without interruption.

A network gateway is used to route traffic between networks and does not address printer addressing issues. A USB cable would eliminate network printing entirely and is not appropriate for a SOHO network environment. APIPA addresses indicate a DHCP failure and would worsen connectivity rather than fix it.

CompTIA strongly emphasizes using static IP addressing for shared network devices such as printers to ensure stability and prevent recurring access problems.

Since the issue only occurs during scanning and copying (not printing or faxing), the problem is isolated to the document feeder. A vertical line is typically caused by debris or damage on theglass under the ADF (Automatic Document Feeder), not on components related to printing.

The most likely cause of slow charging after borrowing a charger is that the borrowed adapter is not the correct wattage or is not fully compatible with the laptop. Many laptops will still charge with an underpowered or non-matching adapter, but they often charge very slowly, may display a warning like “plugged in, not charging fast,” or may reduce performance to stay within the available power budget. In CompTIA A+ Core 1 troubleshooting, the first step is to check the simplest and most probable cause, especially when the symptom began immediately after a change. Using the proper manufacturer-recommended charger (correct voltage/amperage and connector type, or correct USB-C PD wattage profile if applicable) restores normal charging behavior in most cases.

Adjusting battery performance settings might reduce power draw but does not address the root cause of insufficient charger output. Trying a different charging port can help if a port is damaged, but the timing strongly points to the borrowed charger. Replacing the battery is the most invasive and least likely first step because the battery was presumably functioning before the charger change. Therefore, the technician should first use a different, known-good power supply with the correct specifications.
