The most likely failed component in this scenario is the touch screen. According to CompTIA Core 1 (220-1201) mobile device hardware and troubleshooting objectives, smartphones rely on the digitizer (touch screen layer) to detect user input such as taps, swipes, and on-screen keyboard presses. If the device powers on and displays the lock screen but does not register code input, this strongly indicates a failure in the touch input functionality.

A failed charging port would prevent the device from charging but would not affect the ability to enter a passcode if the device is powered on. An OLED failure would result in display issues such as a blank screen, flickering, discoloration, or no image at all—none of which are described in this scenario. A biometric scanner (fingerprint or facial recognition) failure would only impact biometric authentication methods; users would still be able to unlock the phone using a PIN or passcode.

CompTIA emphasizes distinguishing between display output issues and input issues when troubleshooting mobile devices. Since the problem specifically involves unsuccessful code entry despite the phone being operational, the root cause is the touch screen.

The accelerometer is the component most likely malfunctioning. A mobile-device accelerometer measures changes in movement, tilt, and orientation along multiple axes. The operating system uses this sensor data to determine whether the device is being held vertically in portrait mode or horizontally in landscape mode. Because automatic rotation is enabled correctly in the software, the failure to detect physical rotation points to a sensor problem rather than a configuration problem. The antenna handles wireless communications such as cellular, Wi-Fi, Bluetooth, or GPS reception and does not detect screen orientation. The front-facing camera captures images and supports video calls or facial-recognition functions. The GPS module determines geographic position using satellite signals but does not control display rotation. A failed or unresponsive accelerometer would therefore prevent the operating system from recognizing that the phone has been rotated and changing the screen orientation accordingly.

A RAID 1 array uses disk mirroring, meaning all data is written identically to two drives. When one drive fails, the other contains a complete, current copy of the data. CompTIA A+ emphasizes that RAID 1 is designed for fault tolerance, allowing continued operation even after a disk failure.

The correct action is to replace the defective drive and allow the RAID controller to rebuild (sync) the mirror onto the new disk. This restores redundancy and ensures ongoing data protection. The system can typically continue running during the rebuild process.

Option A is incorrect because attempting to repair a failed drive is unreliable and unnecessary—RAID 1 already provides a healthy copy. Option B ignores the importance of restoring redundancy, leaving the system vulnerable to data loss if the remaining drive fails. Option D (restore from backup) is unnecessary because RAID 1 already preserves the data.

Therefore, the best solution is to install a new drive and resynchronize the array, preserving all data with minimal disruption.

The workstation ' s IP configuration (192.168.1.27/24 with gateway 192.168.1.1) shows that it has a correct IP address, correct subnet mask, and expected default gateway for a typical small office network. Because the IP is in the correct private range and not an APIPA address (169.254.x.x), this also confirms that DHCP is functioning properly. Therefore, option D (DHCP) cannot be the cause.

The user then pings the default gateway at 192.168.1.1, which should be the router—the device providing routing between local devices and outside networks. The repeated " Request timed out " responses indicate the workstation cannot reach the router at all. This type of failure points directly to a router outage, a powered-off router, a failed router interface, or a physical disconnection of the router from the switch.

If DNS (C) were the issue, the user would still be able to ping the IP address of the gateway because DNS is not required for IP-to-IP connectivity. A web server (A) has no relation to local gateway communication and does not affect workstation access.

Since the workstation has a valid IP but cannot reach its default gateway, the failure point is the router.

Cellular networks offer broad coverage in rural or less populated areas where laying fiber, cable, or DSL lines may not be feasible or cost-effective. Cellular broadband (4G LTE/5G) provides fast speeds using existing mobile network infrastructure.

From CompTIA A+ 220-1101 Official Study Guide, Objective 2.7 – Compare and contrast Internet connection types:

" Cellular connections offer high speed and extensive coverage, especially in areas where other wired infrastructure may not exist or be practical. "

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 2: Internet Connections

CompTIA Exam Objectives 220-1101, Domain 2.7

============

When port issues persist after moving to a different switch port, the next logical troubleshooting step is to test the patch cable. Faulty or damaged cables are a common cause of network connectivity problems. Using a cable tester between the computer and the network closet verifies the integrity of the cable and rules out a physical layer issue.

From CompTIA A+ 220-1101 Official Study Guide, Objective 4.2 – Troubleshoot wired and wireless networks:

“If a device continues to experience connectivity issues after switching ports, test the cabling with a cable tester to check for continuity, shorts, or pinout issues before replacing hardware.”

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 4: Troubleshooting Network Connectivity

CompTIA Exam Objectives 220-1101, Domain 4.2

============

Improper seating is the most common reason an SSD isn’t recognized. Ensuring it is correctly connected resolves the issue.

Why Not A (Faulty SSD): A faulty SSD is possible but less likely than an installation issue.

Why Not B (Not formatted): Formatting affects data usability, not drive detection.

Why Not C (Incompatibility): SSD compatibility issues are rare with modern hardware.

CompTIA A+ Exam Reference: Core 1 (220-1201), Section 3.3, storage troubleshooting​.

DisplayPort is a fully digital video interface that supports HDCP (High-bandwidth Digital Content Protection), a digital rights-management protocol used to protect copyrighted content such as movies, streaming video, and Blu-ray playback. The CompTIA A+ study guide notes that DisplayPort and HDMI support HDCP, while analog connections like VGA and DVI-A do not support HDCP because analog signals cannot enforce digital content protection.

F-type connectors are used for coaxial cabling (cable TV, satellite), not digital video output. DisplayPort ' s support for encrypted high-definition video streams makes it the correct answer and aligns with CompTIA’s coverage of display connectors and digital content protection technologies.

Elasticity in cloud computing refers to the ability of a system to automatically allocate and release resources (such as CPU, RAM, or virtual machines) as workload demands change. This feature is key to ensuring that resources are used efficiently without manual intervention.

A Layer 3 switch is the optimal solution when multiple VLANs must intercommunicate while maintaining high performance and minimal hardware complexity. CompTIA A+ explains that Layer 3 switches combine the capabilities of switching (Layer 2) and routing (Layer 3), allowing VLAN traffic to be routed internally at wire speed, without the latency typically associated with traditional routers.

Layer 3 switches use hardware-based routing, meaning they forward inter-VLAN traffic using ASICs (Application-Specific Integrated Circuits). This allows them to achieve extremely fast throughput, ideal for environments like computer training institutes where multiple VLANs may be used for student labs, instructor networks, and administrative traffic.

A router (D) can route between VLANs but introduces more latency due to software-based routing and typically requires additional equipment. A Web application firewall (A) and DDoS appliance (B) are security devices unrelated to internal VLAN communication.

Because the institute requires minimal hardware and high-speed inter-VLAN communication, the Layer 3 switch is the only CompTIA-supported device that meets both requirements simultaneously.
