A router is a network device that forwards data between different networks by examining packet headers, specifically the IP address information contained in Layer 3 (Network Layer) of the OSI model. According to the CompTIA A+ Core 1 (220-1201) networking objectives, routers use routing tables and packet header analysis to determine the best path for data to travel from a source network to a destination network. When a packet arrives at a router interface, the router reads the destination IP address in the packet header, compares it against its routing table, and then forwards the packet to the appropriate next hop or network interface. This function allows routers to connect multiple networks such as LANs, WANs, and the internet.

The other options do not perform this function. A hub operates at Layer 1 (Physical Layer) and simply broadcasts incoming signals to all connected ports without inspecting any packet information. A repeater also operates at the physical layer and is used only to regenerate or amplify signals to extend network distance. An unmanaged switch operates mainly at Layer 2 (Data Link Layer) and forwards frames based on MAC addresses, not IP packet headers. Because only routers analyze packet headers and forward traffic between different networks, Router is the correct answer.

Desktop computers most commonly use DIMM modules (Dual Inline Memory Module) for system memory. DIMMs are the standard full-size RAM sticks installed in desktop motherboard memory slots and are available in modern DDR generations such as DDR4 and DDR5. CompTIA A+ Core 1 expects you to distinguish common form factors: desktops use DIMM, while laptops typically use SO-DIMM (Small Outline DIMM).

The other options are either specialized memory types or not the typical “type” used to describe desktop installation. Static refers to SRAM (static RAM), which is used for CPU cache and other internal high-speed buffers, not for installing system RAM modules in a desktop. ECC (Error-Correcting Code) memory is used mainly in servers/workstations where data integrity is critical and requires motherboard/CPU support; it is not the most likely choice for a typical desktop upgrade. Registered (buffered) memory is also primarily for servers and compatible platforms, improving stability with large memory configurations but not common in standard desktops. Therefore, the best answer for typical desktop RAM installation is DIMM.

A blinking orange light typically indicates a failed hard drive in the RAID array. In RAID 1 (mirroring), you can replace the failed drive and rebuild the array without data loss.

From CompTIA A+ 220-1101 Official Study Guide, Objective 3.4 – RAID configuration and troubleshooting:

" In the event of a hard drive failure in RAID 1, replace the failed disk and allow the array to rebuild using the remaining mirrored disk. "

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 3: RAID and Storage

CompTIA Exam Objectives 220-1101, Domain 3.4

============

The correct answer is C. Synchronized system clocks .

According to CompTIA A+ Core 1 220-1201 objectives under Networking and Server Services, NTP (Network Time Protocol) is used to synchronize the clocks of computers across a network to a common time source. This is critical for:

Ensuring accurate timestamps for logs and events.

Coordinating scheduled tasks across multiple systems.

Preventing authentication issues in environments that rely on time-based credentials (e.g., Kerberos).

Why the other options are incorrect:

A. Defined network transport protocols: NTP itself is a protocol that uses UDP, but its primary purpose is not defining transport protocols.

B. Enabled print services on the server: NTP does not relate to printing.

D. Defined server options in DHCP: NTP may be referenced by DHCP options, but the act of adding NTP to a server is focused on time synchronization, not DHCP configuration.

An IP address starting with169.254.x.xis aself-assigned address(also calledAPIPA– Automatic Private IP Addressing). It’s used when a client device cannot contact a DHCP server. This address allows limited communication on the local network segment butno internet access.

Option A:DHCP reservations assign specific IPs from the DHCP server they don’t result in APIPA.

Option B:Dynamic assignment from DHCP assigns valid IPs in the proper subnet, not 169.254.x.x.

Option D:Static IPs are manually set and would not fall in the 169.254.x.x range unless set incorrectly.

CompTIA A+ Core 1 Exam Objective Reference:

Objective 2.6: Given a scenario, configure and troubleshoot network connectivity.

An eSIM (embedded SIM) allows users to change carriers and provision new cellular service without installing any physical hardware. It is managed via software and is ideal for international travelers who need to switch providers quickly.

From the CompTIA A+ 220-1101 Official Study Guide, Objective 3.3 – Install and configure mobile device network connectivity:

" eSIMs provide carrier flexibility by enabling remote provisioning and profile switching, making it possible to connect to different networks without a physical SIM card. "

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 3: Mobile Devices

CompTIA Exam Objectives 220-1101, Domain 3.3

Badging is a form of authentication that requires employees to use a badge or ID card to release print jobs. This solution reduces unnecessary printing by ensuring only authorized users print.

Why Not A (Access control list): While ACLs manage permissions, they are not used for physical authentication at printers.

Why Not B (Audit logging): Audit logs track actions but do not restrict printer access.

Why Not D (Print server): A print server manages print jobs but doesn’t enforce authentication.

CompTIA A+ Exam Reference: Core 2 (220-1102), Section 2.5, authentication mechanisms​.

CompTIA A+ divides hypervisors into two main categories: Type 1 (bare-metal) and Type 2 (hosted). A Type 2 hypervisor runs on top of an existing host operating system such as Windows, macOS, or Linux. It relies on the host OS for device drivers, hardware interaction, and resource management. Examples include VMware Workstation, Oracle VirtualBox, and Parallels Desktop.

Type 2 hypervisors are ideal for lab environments, testing, learning, and small-scale virtualization because they do not require dedicated hardware or direct hardware control. The host OS loads first, and the hypervisor runs as an application, allowing users to create and manage virtual machines from within the OS environment.

Option B describes a Type 1 hypervisor, which installs directly on hardware without a host OS. Option A is unrelated, as firewalls are separate from virtualization technology. Option D is incorrect because hypervisors do not inherently increase CPU capabilities; they merely allocate existing hardware resources to virtual machines.

Thus, the correct and CompTIA-aligned description of a Type 2 hypervisor is that it runs on a host operating system.

Large electrical motors can emit electromagnetic interference (EMI), which can disrupt wireless signals and prevent connectivity.

From CompTIA A+ 220-1101 Official Study Guide, Objective 2.4 – Wireless troubleshooting:

“Sources of external interference such as motors or other electrical equipment can disrupt wireless network connectivity.”

Verified Source:

CompTIA A+ Core 1 (220-1101) Official Study Guide, Chapter 2: Networking Troubleshooting

CompTIA Exam Objectives 220-1101, Domain 2.4

============

Intermittent connectivity issues with network printers are commonly caused by changing IP addresses when using DHCP. Assigning a static IP address ensures that the printer is always reachable at the same IP address by client machines.
