A network engineer is asked to describe the cloud infrastructure models from the perspective of their operation and access to resources. Drag and drop the descriptions from the left onto the appropriate.

An engineer must tune an FCIP connection over WAN between two Cisco MDS 9000 Series Switches The customer has determined that default TCP parameters do not function for the link with 300 ms latency The TCP profile must

    Modify the TCP retransmit time to satisfy the WAN latency.

    Set the TCP keepalive timeout to 15 seconds.

    Set the maximum number of TCP retransmissions to 5

Which command set meets the requirements?

A.

Option A

B.

Option B

C.

Option C

D.

Option D

An engineer is implementing the Cisco ACI fabric and must create two different vPCs from leaf switches A and B. The vPCs are deployed as follows:

    vPC 1 encompasses ports Eth 1 /1 on leaf A and B and connects to server 1.

    vPC 2 encompasses port Eth1/2 on leaf A and B and connects to server 2.

A leaf switch profile listing leaves A and B is already configured Which ACI object must be created to meet these requirements?

A.

two vPC interface policy groups

B.

one access port interface policy group

C.

two PortChannel interface policy groups

D.

one vPC interface policy group

Refer to the exhibit. An engineer is troubleshooting a connection issue from the virtual machine that is located on the Webserver 1 blade. The application team requested a packet capture for all traffic that is transferred to and from Webserver 1. The engineer confirmed that the host server vNIC1 has VLAN 300 assigned to It. Which action must be taken to capture the traffic?

A.

Configure a span session that Is sourced from Eth1/1 with a destination that is set to port channel 1.

B.

Configure a span session that Is sourced from Eth1/3 with a destination that Is set to Ethl/2.

C.

Configure a span session that Is sourced from port channel 1 with a destination that Is set to port channel 2.

D.

Configure a span session that Is sourced from service profile vNlCi with a destination that is set to Ethl/3.

Refer to the exhibit. A source is sending a multicast traffic stream to the receiver. How is the multicast traffic expected to flow through the network when it reaches a vPC peer?

A.

The multicast traffic is not replicated to the ports that joined a multicast group (224.0.0.13) or the peer link. The multicast traffic stream flows from Agg-1 to Agg-2 over the M1-to-M2 peer link and forwards the traffic over Layer 4 to Access-2.

B.

The multicast traffic is replicated to the ports that joined a given multicast group and the peer link. The multicast traffic stream flows from Agg-1 to Agg-2 over the M1-to-M2 peer link and forwards the traffic over Layer 4 to Access-2.

C.

The multicast traffic is not replicated to the ports that joined a multicast group (224.0.0.13) or the peer link. The multicast traffic stream flows over the vPC link to ensure that orphan ports get the multicast stream in failure scenarios.

D.

The multicast traffic is replicated to the ports that joined a given multicast group and the peer link. The multicast traffic stream flows over the peer link to ensure that orphan ports receive the multicast stream in failure scenarios.

An engineer must authenticate OSPF on interfaces of me Cisco Nexus 9000 Senes Switch so mat

    eth1/1 uses clear text password

    etht'2 uses encrypted md5 password

Drag and drop the commands from the bottom onto the boxes in the code to complete me configuration Not all commands are used.

Which Cisco UCS component does an infra bundle “A” software upgrade?

A.

BIOS

B.

I/O module

C.

adapter

D.

board controller

What is the primary purpose of a UCS Domain Profile in Intersight Managed Mode?

A.

It creates the common configuration for a group of fabric interconnects.

B.

It orchestrates data center operations across multiple domains.

C.

It provides a centralized repository for UCS Manager backups

D.

It manages individual service profiles for UCS servers

Refer to the exhibit. An engineer must invoke a Python script that alerts the operations team when the router DC-RTR-1 becomes unreachable. Which configuration set accomplishes this task?

A.

track 3 ip sla 10 reachability

event name GATEWAY-DOWN

event state down

action cli command routerdown.py

B.

scheduler job name ROUTER-DOWN

job track 9 state down

action 1.0 cli source routerdown.py

schedule 10

C.

event scheduler name DOWN-ROUTER

event track 2 state 1 not up

event action 1.0 command source routerdown.py

event start 0:00 repeat 0:05

D.

event manager applet ROUTER-DOWN-SLA

event track 5 state down

action 1.0 event-default

action 2.0 cli command source routerdown.py

Which API standard is used to manage the UCS-X in Intersight Managed Mode?

A.

Blowfish

B.

XML

C.

WebRTC

D.

Redfish
