Refer to the exhibit.

An administrator just upgraded to Cisco UCM to version 14 and started SIP implementation with some new SIP trunks. During the testing, an error was reported when making a call. Which action resolves the issue?

A.

Change to a valid range.

B.

Change DTMF Signaling Method to "RFC 4833*.

C.

Make sure the destination number is configured correctly and the device is registered.

D.

Disable SIP Rel1XX Options.

Refer to the exhibit.

DN 1003 was the last to ring during the most recent call. Which hunting method ensures that DN 1005 is presented with the next call when the hunt pilot is dialed?

A.

call-blast

B.

parallel

C.

sequential

D.

peer

An administrator is asked to configure egress call routing by applying globalization and localization on Cisco UCM. How should this be accomplished?

A.

Localize the calling and called numbers to PSTN format and globalize the calling and called numbers in the gateway.

B.

Globalize the calling and called numbers to PSTN format and localize the calling number in the gateway.

C.

Localize the calling and called numbers to E. 164 format and globalize the called number in the gateway.

D.

Globalize the calling and called numbers to E. 164 format and localize the called number in the gateway.

An engineer uses the standard local route group to configure call routing for the organization. The engineer configured an additional local route group with a unique name.

Which action must be taken to ensure that each device in the system is provisioned to know its local route group?

A.

Configure route filters

B.

Add the local route group to a route list

C.

Associate the local route group with a device pool

D.

Add the local route group to a translation pattern

Signal number reach call phone that not answered are leaving voicemails on the cell phone rather the corporate mailbox. Which two options will resolve this issue? (Choose two.)

A.

Check the Enable Extend and Connect checkbox

B.

Check the Enable Unified Mobility features checkbox

C.

Decrease the T302 timer

D.

Decrease the T301 timer Decrease the Answer Too Late timer

For s SIP to SIP call flow, when does Cisco Unified Border Element require transcoding resources for DTMF?

A.

interworking between an OOB method and RFC2833 for flow-around calls

B.

interworking between h245-signal and rtp-nte

C.

interworking between an OOB method and RFC2833 for flow-through calls

D.

interworking between h245-alpha numeric and sip-kpml

An administrator is configuring an Intercluster Lookup Service between 10 Cisco UCM clusters. Due to security requirements, certificate-based authentication must be used. Due to the deployment size, the administrator wants to avoid manually exchanging certificates between the clusters. Which two steps must be followed to meet these requirements? (Choose two)

A.

Set all dusters to standalone on the ILS configuration page.

B.

Install multiserver CA-signed Tomcat certificates on all cluster publishers.

C.

Enable password-based authentication in conjunction with certificate-based authentication.

D.

Ensure that the cluster ID for all clusters is the same.

E.

Install multiserver CA-signed CallManager certificates on all cluster publishers.

Refer to the exhibit.

A no-way audio situation was experienced after the calling party on an outbound call placed the call on hold and then resumed from hold. Which action will resolve the issue?

A.

Assign an MTP to the SIP trunk.

B.

Restart the SIP trunk on Cisco UCM.

C.

Upgrade the Cisco Unified Border Element to 15.2.

D.

Upgrade the Cisco Unified Border Element device.

Refer to the exhibit.

Users report high delays when calling national numbers in the United States. An engineer analyzes the route patterns in Cisco UCM. What must be done to resolve this issue?

A.

Change the Cisco UCM routing logic to the longest-match algorithm.

B.

Select Allow Overlap Sending for the \+! route pattern.

C.

Mark the \+ [2-9JXX[2-91XXXXXX route pattern with urgent priority.

D.

Set the interdigit timeout service parameter value to 0.

A user reports when they press the services key they do not receive a user ID and password prompt to assign the phone extension. Which action resolves the issue?

A.

Create the default device profiles for all phone models that are used.

B.

Subscribe the phone to the Cisco Extension Mobility service.

C.

Create the end user and associate it to the device profile.

D.

Assign the extension as a mobile extension.
