An engineer must build a VXLAN flood-and-learned network. The customer requires the solution to be based on the IETF documented practice in RFC 7348. The solution must use broadcast, unknown unicast, and multicast (BUM) and include the efficient BUM and short BUM replication modes that use only shared trees. Which technology meets these requirements?
Which two configurations are available by using a service profile template in Cisco UCS Manager? (Choose two.)
A customer needs a design for a new data center network that meets these requirements:
Logically partition the environment into separate security domains.
Cut costs related to purchasing additional equipment.
Separate routing processes, TCAM, QoS tables, and data planes.
Which technology must be used?
Which feature must be configured to connect a classical Ethernet network to a data center network so that the data center network appears to be one large switch.
Refer to the exhibit During a synchronization of port rotes, a device receives a proposal message on one of its ports that is selected as the new root port. The logs show that Rapid PVST+forced all other ports to synchronize with the new loot information. The engineer analyzes the port stales and concludes that the device is synchronized with superior root information received on the root port, and all other ports are synchronized. What happens to a designated port that is in the forwarding state and is not configured as an edge port, if Rapid PVST+ forces it to synchronize with new root information?
An engineer designs a Cisco UCS solution that must provide guaranteed and deterministic bandwidth to a specific server in the environment. The solution must apply to network and storage traffic of C-Series and B-Series servers. Which solution should be included to meet these requirements?
An engineer must design a solution based on Cisco Nexus 7709 Switches. The solution must connect test and development network segments and separate the enterprise applications from the production network. The network security team requires routing instances and the IP stack to be completely separated from each other and for traffic between the environments to undergo a deep packet inspection. The development team also requests the ability to allocate additional physical interfaces from the Cisco Nexus 7709 device in each environment.
Which solution meets these requirements?
A network engineer is connecting a backup server to the given network The server has three available physical Ethernet interfaces - dual 1Gbps interfaces, plus a single 10Gbps interface - and all devices support virtual port channels The engineer must minimize backup time from hosts on the network, with a mandate for no single point of failure connectivity within the data center and the interfaces either active or passive Which deployment model must the engineer use?
A)
B)
C)
D)
An engineer must design a DNS service available to multiple network zones as a shared service. The network zones are deployed as VRFs within the data center network and no firewall is available for communication between VRFs.
Which protocol is needed to implement the shared services?
Which type of Cisco Intersight workflow input controls the availability of other specific workflow inputs during the execution of a workflow?
