Free Practice Questions for Cisco 300-425 Exam

 For an active survey where the application requires a minimum RF of -73 dBm, the mobile device used for the survey should have a receiver sensitivity of -70 dBm or better. This ensures that the device is sensitive enough to detect the minimum required signal strength for the application to function properly.

The issue described indicates that there are more critical priority access points than the backup Cisco WLC can handle with its available licenses. Since there are only 10 licenses available and 7 access points are set to critical priority, not all of them can failover when the primary Cisco WLC is at full capacity. This oversubscription of critical priority access points prevents all of them from failing over as expected.

References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide

The IEEE 802.11k protocol is designed to enable radio resource measurement and neighbor list radio management packets. This protocol allows wireless devices to better understand their radio environment, which in turn supports real-time applications over wireless by enabling devices to make quicker and more informed decisions about roaming

The 9800 Series Wireless Controller uses CAPWAP tunnels to encapsulate and transport both control and data traffic between access points and the controller. This allows for centralized management and control while also enabling efficient data forwarding.

https://www.cisco.com/c/en/us/td/docs/wireless/controller/9800/config-guide/b_wl_16_10_cg/mobility.html

When the mobility tunnel is not operational for the data path, it is essential to validate the network’s firewall settings. Firewall port 16666 must be open to allow mobility control messages to pass through, and firewall IP protocol 97 (EtherIP) must be permitted to enable the encapsulation of IP within IP, which is necessary for the data path of the mobility tunnel. Ensuring these firewall settings are correctly configured is critical for facilitating inter-controller roaming and operational mobility tunnels.

For predictive designs, especially for location readiness and interference mitigation, a mid-range power level like 18 mw is often used. It provides a balance between coverage and minimizing interference with other devices and networks.

 Smartphones and tablets typically have fewer antennas than laptops, which can affect their signal reception and transmission capabilities. Additionally, they often support lower data rates compared to laptops due to their smaller size and power constraints.

 In environments with high client density, deploying APs for 5 GHz coverage is recommended due to the larger number of non-overlapping channels available, which can support higher data rates and client capacity. Disabling the 2.4 GHz radios on some APs can reduce interference and improve overall network performance.

https://www.cisco.com/c/en/us/td/docs/wireless/controller/technotes/86/b_Cisco_Wireless_LAN_Controller_Configuration_Best_Practices.html

An SNR (Signal-to-Noise Ratio) less than 15 dB within the cell boundary during an AP-on-a-stick survey indicates that there is interference affecting the AP’s signal. This interference could be from another signal source that is reducing the quality of the connection, despite the signal strength being within the acceptable cell boundary of -67 dBm.
