Free Practice Questions for Splunk SPLK-2002 Exam

 The Splunk instance with the given settings in SPLUNK_HOME/etc/system/local/server.conf is missing the master_uri attribute and needs to be restarted. The master_uri attribute is required for the master node to communicate with the peer nodes and the search head cluster. The master_uri attribute specifies the host name and port number of the master node. Without this attribute, the master node cannot function properly. The Splunk instance also needs to be restarted for the changes in the server.conf file to take effect. The replication_factor setting determines how many copies of each bucket are maintained across the peer nodes. The search factor is a separate setting that determines how many searchable copies of each bucket are maintained across the peer nodes. The search factor is not specified in the given settings, so it defaults to the same value as the replication factor, which is 2. This is not a multi-site cluster, because the site attribute is not specified in the clustering stanza. A multi-site cluster is a cluster that spans multiple geographic locations, or sites, and has different replication and search factors for each site.

The Splunk server name of the member can typically be determined by the serverName attribute in the server.conf file, which is not explicitly shown in the provided snippet. However, based on the provided configuration snippet, we can infer that this search head cluster member is configured to communicate with a cluster master (master_uri) located at node1 and a management node (mgmt_uri) located at node3. The serverName is not the same as the master_uri or mgmt_uri; these URIs indicate the location of the master and management nodes that this member interacts with.

Since the serverName is not provided in the snippet, one would typically look for a setting under the [general] stanza in server.conf. However, given the options and the common naming conventions in a Splunk environment, node3 would be a reasonable guess for the server name of this member, since it is indicated as the management URI within the [shclustering] stanza, which suggests it might be the name or address of the server in question.

For accurate identification, you would need to access the full server.conf file or the Splunk Web on the search head cluster member and look under Settings > Server settings > General settings to find the actual serverName. Reference for these details would be found in the Splunk documentation regarding the configuration files, particularly server.conf.

The deployer is a Splunk Enterprise instance that distributes apps and other configurations to the members of a search head cluster1.

The deployer cannot share functionality with any other Splunk Enterprise instance, including the license master, the master node, or the monitoring console2.

However, the search head cluster members can share functionality with the master node and the monitoring console, as long as they are not designated as the captain of the cluster3.

Therefore, the correct answer is B. License master, as it is the only instance that cannot share functionality with the deployer under any circumstances.

References: 1: About the deployer 2: Deployer system requirements 3: Search head cluster architecture

The correct configuration attribute to set in server.conf on the cluster manager in a single-site indexer cluster is master_uri. This attribute specifies the URI of the cluster manager, which is required for the peer nodes and search heads to communicate with it1. The other attributes are not required for a single-site indexer cluster, but they are used for a multisite indexer cluster. The site attribute defines the site name for each node in a multisite indexer cluster2. The replication_factor attribute defines the number of copies of each bucket to maintain across the entire multisite indexer cluster3. The site_replication_factor attribute defines the number of copies of each bucket to maintain across each site in a multisite indexer cluster4. Therefore, option A is the correct answer, and options B, C, and D are incorrect.

1: Configure the cluster manager 2: Configure the site attribute 3: Configure the replication factor 4: Configure the site replication factor

Splunk configuration files are files that contain settings that control various aspects of Splunk behavior, such as data inputs, outputs, indexing, searching, clustering, and so on1. Troubleshooting Splunk configuration files involves identifying and resolving issues that affect the functionality or performance of Splunk due to incorrect or conflicting configuration settings. Some of the tools and methods that can help with troubleshooting Splunk configuration files are:

search.log: This is a file that contains detailed information about the execution of a search, such as the search pipeline, the search commands, the search results, the search errors, and the search performance2. This file can help troubleshoot issues related to search configuration, such as props.conf, transforms.conf, macros.conf, and so on3.

btool output: This is a command-line tool that displays the effective configuration settings for a given Splunk component, such as inputs, outputs, indexes, props, and so on4. This tool can help troubleshoot issues related to configuration precedence, inheritance, and merging, as well as identify the source of a configuration setting5.

diagnostic logs: These are files that contain information about the Splunk system, such as the Splunk version, the operating system, the hardware, the license, the indexes, the apps, the users, the roles, the permissions, the configuration files, the log files, and the metrics6. These files can help troubleshoot issues related to Splunk installation, deployment, performance, and health7.

Option A is the correct answer because crash logs are the least helpful in troubleshooting Splunk configuration files. Crash logs are files that contain information about the Splunk process when it crashes, such as the stack trace, the memory dump, and the environment variables8. These files can help troubleshoot issues related to Splunk stability, reliability, and security, but not necessarily related to Splunk configuration9.

References:

1: About configuration files - Splunk Documentation 2: Use the search.log file - Splunk Documentation 3: Troubleshoot search-time field extraction - Splunk Documentation 4: Use btool to troubleshoot configurations - Splunk Documentation 5: Troubleshoot configuration issues - Splunk Documentation 6: About the diagnostic utility - Splunk Documentation 7: Use the diagnostic utility - Splunk Documentation 8: About crash logs - Splunk Documentation 9: [Troubleshoot Splunk Enterprise crashes - Splunk Documentation]

The client filters available in serverclass.conf are DNS name, IP address, and platform (machine type). These filters allow the administrator to specify which forwarders belong to a server class and receive the apps and configurations from the deployment server. The Splunk server role is not a valid client filter in serverclass.conf, as it is not a property of the forwarder. For more information, see [Use forwarder management filters] in the Splunk documentation.

 Search head clustering is a Splunk feature that allows a group of search heads to share configurations, apps, and knowledge objects, and to provide high availability and scalability for searching. Search head clustering has the following characteristics:

A deployer is required. A deployer is a Splunk instance that distributes the configurations and apps to the members of the search head cluster. The deployer is not a member of the cluster, but a separate instance that communicates with the cluster master.

At least three search heads are needed. A search head cluster must have at least three search heads to form a quorum and to ensure high availability. If the cluster has less than three search heads, it cannot function properly and will enter a degraded mode.

The deployer must have sufficient CPU and network resources to process service requests and push configurations. The deployer is responsible for handling the requests from the cluster master and the cluster members, and for pushing the configurations and apps to the cluster members. Therefore, the deployer must have enough CPU and network resources to perform these tasks efficiently and reliably.

Search heads do not need to meet the high-performance reference server requirements, as this is not a mandatory condition for search head clustering. The high-performance reference server requirements are only recommended for optimal performance and scalability of Splunk deployments, but they are not enforced by Splunk.

The following statements describe a search head cluster captain:

Is the job scheduler for the entire search head cluster. The captain is responsible for scheduling and dispatching the searches that run on the search head cluster, as well as coordinating the search results from the search peers. The captain also ensures that the scheduled searches are balanced across the search head cluster members and that the search concurrency limits are enforced.

Replicates the search head cluster’s knowledge bundle to the search peers. The captain is responsible for creating and distributing the knowledge bundle to the search peers, which contains the knowledge objects that are required for the searches. The captain also ensures that the knowledge bundle is consistent and up-to-date across the search head cluster and the search peers. The following statements do not describe a search head cluster captain:

Manages alert action suppressions (throttling). Alert action suppressions are the settings that prevent an alert from triggering too frequently or too many times. These settings are managed by the search head that runs the alert, not by the captain. The captain does not have any special role in managing alert action suppressions.

Synchronizes the member list with the KV store primary. The member list is the list of search head cluster members that are active and available. The KV store primary is the search head cluster member that is responsible for replicating the KV store data to the other members. These roles are not related to the captain, and the captain does not synchronize them. The member list and the KV store primary are determined by the RAFT consensus algorithm, which is independent of the captain election. For more information, see [About the captain and the captain election] and [About KV store and search head clusters] in the Splunk documentation.

Multiple search pipelines should be enabled only if CPU and memory resources are significantly under-utilized. Search pipelines are the processes that execute search commands and return results. Multiple search pipelines can improve the search performance by running concurrent searches in parallel. However, multiple search pipelines also consume more CPU and memory resources, which can affect the overall system performance. Therefore, multiple search pipelines should be enabled only if there are enough CPU and memory resources available, and if the system is not bottlenecked by disk I/O or network bandwidth. The number of concurrent users, the disk IOPS, and the Splunk Enterprise version are not relevant factors for enabling multiple search pipelines
