Free Practice Questions for Nutanix NCP-CI-AWS Exam

To SSH into a Controller VM (CVM) in an NC2 on AWS cluster without on-premises connectivity, the administrator needs to ensure that the security settings allow SSH access from the Jump Host. This involves editing the User Management Network Security Group to permit SSH traffic from the Jump Host IP.

Deploy Jump Host:

Ensure the Jump Host is deployed in a public subnet with an Elastic IP (EIP) assigned for external access.

Edit User Management Network Security Group:

Locate the security group associated with the user management network.

Modify the inbound rules to allow SSH (port 22) from the Jump Host's IP address. This ensures that the Jump Host can establish an SSH connection to the CVM.

Steps to Edit Security Group:

Navigate to the EC2 dashboard in the AWS Management Console.

Select "Security Groups" under the "Network & Security" section.

Find and select the appropriate security group.

Edit the inbound rules to add a new rule:

Type: SSH

Protocol: TCP

Port Range: 22

Source: Custom IP (enter the Jump Host's public IP address)

Additional Configuration:

Ensure that the CVM itself allows SSH connections and that no internal firewall rules block the traffic.

References:

Nutanix Cloud Clusters on AWS Administration Guide

AWS Security Group Documentation

Nutanix Best Practices for Secure Access

The role of "Customer Administrator" in Nutanix Cloud Integration with AWS (NC2) is designed to meet the requirements of creating and managing multiple organizations and clusters, as well as managing user access for the entire company.

Roles and Permissions:

Customer Administrator: This role has the broadest set of permissions, allowing the user to create and manage organizations, clusters, and user access across the entire company. It encompasses administrative control over multiple aspects of the NC2 environment.

Capabilities:

Organization Management: Ability to create and manage multiple organizations.

Cluster Management: Full control over creating, configuring, and managing clusters.

User Access Management: Manage user roles and permissions, ensuring that the right individuals have access to the necessary resources.

Why Not Other Roles:

Organization Administrator: Limited to managing organizations but not clusters and user access at the company level.

Customer Security Administrator: Focuses on security aspects, lacking broader administrative capabilities.

Cluster Administrator: Limited to managing clusters without the ability to manage organizations and user access comprehensively.

References:

Nutanix Cloud Clusters on AWS Administration Guide

Nutanix Role-Based Access Control Documentation

The Nutanix disaster recovery capabilities include recovery plans that define how entities are recovered in the event of a failure. There is a limit to the number of entities that can be managed within a single recovery plan.

Entity Limit:

According to Nutanix documentation, the maximum number of entities that can be recovered using a single recovery plan is 300. Exceeding this limit will cause issues during the execution of the recovery plan.

Impact of Exceeding the Limit:

If the number of entities in a recovery plan exceeds the supported limit, the recovery process may fail or not execute correctly, as observed in the scenario.

References:

Nutanix Cloud Clusters on AWS Administration Guide

Nutanix Disaster Recovery Best Practices Documentation

Before accessing the Nutanix Cloud Clusters (NC2) console, the first step is to create a My Nutanix account.

This account serves as the primary gateway for managing and accessing Nutanix services, including NC2.

Once the account is created, users can log in to the Nutanix portal, where they can manage their subscriptions, start trials, and access various Nutanix services, including the NC2 console.

References:Refer to the Nutanix documentation on getting started with NC2 and the My Nutanix account creation process.

When selecting the NC2 subscription plan from the Nutanix Billing portal, the available options include:

Pay-as-you-Go (PayG): A flexible payment option where users are billed based on their actual usage, providing cost efficiency for variable workloads.

Bring your own License (BYOL): Allows users to utilize existing Nutanix licenses they have purchased, offering a cost-effective way to leverage existing investments in Nutanix software.

References:Refer to the Nutanix billing and subscription documentation for detailed descriptions of subscription plans and their benefits.

With the Nutanix AOS Pro licensing, several advanced features and add-on products become available. Specifically, in the AWS cluster deployment wizard, the following add-ons are available:

Files:

Nutanix Files provides a software-defined, scale-out file storage solution that simplifies the management and scaling of unstructured data.

Advanced Replication:

Advanced Replication features in Nutanix include synchronous and asynchronous replication capabilities, allowing for robust disaster recovery and data protection solutions.

DARE (Data-At-Rest Encryption):

DARE ensures that all data stored on Nutanix clusters is encrypted, providing a higher level of security for sensitive information.

These features are included in the AOS Pro licensing tier, offering enhanced data management, protection, and security capabilities.

References:

Nutanix Licensing Guide

Nutanix Cloud Clusters on AWS Administration Guide

Nutanix Best Practices for Advanced Features

To ensure that only application servers from the source subnet 10.79.1.0/24 can access the SQL databases running on the NC2 cluster in the subnet 10.78.1.0/24, the administrator can take the following actions:

Option A: Create a custom Security Group with the following rules:

Key = tag:nutanix:clusters

Key = tag:nutanix:clusters:external

and value = the clusters' UUID

Key = tag:nutanix:clusters:external

and value = 10.78.1.0/24

Option D: Create a custom Security Group with the following:

Key = nutanix:clusters

Key = nutanix:clusters:external

and value = the clusters' UUID

Key = nutanix:clusters:external

and value = 10.79.1.0/24

These actions help create security rules that restrict access to the databases only from the specified source subnet, ensuring secure and controlled access.

References:

Nutanix Cloud Clusters on AWS Administration

AWS Security Groups Documentation

When planning to leverage NC2 on AWS for an elastic DR scenario where the initial cluster is using 13en.metal, the following additional node types are supported for cluster expansion:

I3.metal: These instances provide high IOPS and low latency with NVMe SSDs, making them suitable for storage-intensive applications.

i4i.metal: These instances offer higher performance with AWS Nitro SSDs, improved network bandwidth, and better compute performance compared to the I3.metal instances.

References:

Nutanix Cloud Clusters on AWS Documentation

Amazon EC2 I4i Instances – AWS

Amazon EC2 I3 Instances – AWS

To create a cluster in Nutanix Cloud Integration with AWS, the role needed is Cluster Super Admin.

The Cluster Super Admin role provides the highest level of privileges required to perform critical operations such as creating, managing, and deleting clusters.

This role is essential for overseeing the cluster setup and configuration processes, ensuring the user has full control over the cluster lifecycle.

References:Refer to the Nutanix documentation on roles and permissions for NC2 on AWS for further details on the capabilities and required permissions for cluster creation.
