Free Practice Questions for International Code Council M2 Exam

In the IMC hydronic piping provisions for ground-source heat pump loop systems, shutoff valves are required on both sides of a pressure-reducing valve . That matches D . Heat-fusion joints and change-in-material joints do not trigger this two-sided shutoff-valve requirement.

The ICC administrative provisions require construction documents to be submitted in two or more sets with the permit application. After approval, one set is retained by the code official and one set is returned to the applicant to be kept on the job site during construction. That is exactly the condition described in Option D . The code does not state that all sets are retained by the code official or that the purpose is to provide subcontractor copies or backup copies.

For cooking equipment with exposed flame and burners , the IMC table for grease-filter mounting position requires a minimum vertical separation of 24 inches between the lowest edge of the grease filter and the cooking surface. That makes B correct.

Based on the specification sheet shown in the exhibit, the hood is fabricated of Type 430 stainless steel , and the optional stainless steel listed is Type 304 . Therefore, the correct answer is C .

The IMC combustion-air provisions require openings used for combustion air to have a minimum cross-sectional dimension of 3 inches . Where ducts are used, they must be of the same cross-sectional area as the openings to which they connect. That makes 3 inches the correct answer, so Option B is correct.

The IMC states that solar thermal equipment exposed to vehicular traffic must be installed not less than 6 feet above the finished floor . It then gives an exception stating that this requirement does not apply where the equipment is protected from motor vehicle impact . Because the height requirement is removed by that exception, the best answer from the choices given is A, directly on finished floor . This is an inference from the exception language.

For a Type B gas vent with a listed vent cap terminating through a flat roof , the minimum required termination height is 1 foot above the roof . That makes Option A correct. This is consistent with gas vent termination tables used with listed Type B vent systems and the code framework for Type B vent terminations.

Under the IMC ventilation table, locker/dressing rooms and sports locker rooms are identified with required mechanical exhaust, while spaces such as guard stations do not carry that same exhaust requirement in the table. A high school locker room falls within the locker-room/sports-locker-room category, so Option C is the correct answer. Gambling casinos and office break rooms are provided outdoor air rates, but they are not the required-exhaust space among these listed choices.

Based on the mechanical plan shown in the exhibit, the gas line between unit heaters 5 and 8 is labeled as 1 inch in diameter. Therefore, the correct answer is B.
