Free Practice Questions for Huawei H12-821_V1.0 Exam

In the topology, SWB's GE0/0/2 is the Root Port because it has the least cost path to the Root Bridge (SWA). SWC's GE0/0/1 is the Designated Port because it forwards traffic to SWA while maintaining the shortest path to the Root Bridge. This setup ensures efficient traffic flow in the spanning tree topology ​.

The virtual MAC address for a VRRP virtual router is determined by the formula 00-00-5E-00-01-[VRID in hexadecimal]. For VRID 3, the hexadecimal equivalent is 03. Thus, the virtual MAC address is 00-00-5E-00-01-03 ​.

To compress the IPv6 address 2001:0DB8:0000:C030:0000:0000:09A0, the following rules are applied:

Remove leading zeros in each hextet (e.g., 0DB8 becomes DB8).

Replace contiguous blocks of zeros with :: (only once in the address).Thus, the compressed form is 2001:DB8:0:C030::9A0 ​.

Understanding DIS Election in IS-IS:

On an IS-IS broadcast network, a Designated Intermediate System (DIS) is elected to create and update pseudonodes for efficient communication.

The election is based on the following criteria:

DIS Priority: The router with the highest priority is elected as the DIS.

Router ID (tie-breaker): If priorities are equal, the router with the highest Router ID is elected.

Analyzing the DIS Priorities and Router IDs:

R1: Priority = 64, Router ID = 1.1.1.1

R2: Priority = 1, Router ID = 2.2.2.2

R3: Priority = 127, Router ID = 3.3.3.3

R4: Priority = 10, Router ID = 4.4.4.4

Among the routers, R3 has the highest DIS priority (127), making it the DIS.

Correct Option:

Option B (R3): Correct, as R3 has the highest priority.

Option A (R1): Incorrect, as its priority is lower (64).

Option C (R4): Incorrect, as its priority is lower (10).

Option D (R2): Incorrect, as its priority is the lowest (1).

When a stack splits, the MAC addresses of the newly formed stacks do not change immediately. Instead, they retain their original MAC addresses until new ones are reassigned during topology updates. This delayed update prevents immediate conflicts and allows MAD (Multiple Active Detection) to handle any resulting issues ​.

A is false – The default value of Local_Pref is 100, not 0.

B is false – Local_Pref is not advertised to EBGP peers, it is only sent to IBGP peers.

C is correct – The Local_Pref value stays constant unless modified by a route-policy or filter.

D is correct – Higher Local_Pref values indicate preferred paths, so BGP prefers the path with the highest Local_Pref among multiple options.

Reference from Huawei HCIP-Datacom-Core Technology Study Guide:

“Local_Pref is used to select the best outbound path for traffic leaving the AS. It is only shared among IBGP peers and defaults to 100. The higher the value, the more preferred the route.”

(Chapter: BGP Path Attributes – Section: Local Preference)

Comprehensive and Detailed Step-by-Step Explanation:

Blackhole Route Issue in BGP:

In IBGP, the next hop of a route learned from an EBGP peer is not changed by default. If an IBGP peer cannot reach the next hop, blackhole routes may occur.

To prevent this, the peer next-hop-local command is used to set the next hop to the local router's IP address.

Other Commands:

peer mpls-local-ifnet: Used in MPLS networks to set the next hop as the local interface address.

peer private-nexthop: Allows advertising private IP addresses as the next hop.

peer next-hop-invariable: Ensures the next hop is not modified during route advertisement, which is the opposite of what is required here.

The filter-policy command in IS-IS is used to control the advertisement and filtering of routing information. However, it does not directly filter LSPs (Link State Packets); instead, it controls route advertisements. The false statement here is that it filters LSPs ​.
