Free Practice Questions for Fortinet FCP_FAZ_AN-7.4 Exam

In FortiAnalyzer, when a playbook is run, each task’s status impacts the overall playbook status. Here’s what happens based on task outcomes:

Status When All Tasks Succeed:

If all tasks finish successfully, the playbook status is marked as Success.

Status When Some Tasks Fail:

If one or more tasks in the playbook fail, but others succeed, the playbook status generally changes to Attention required. This status indicates that the playbook completed execution but requires review due to one or more tasks failing.

This is different from a complete Failed status, which is used if the playbook cannot proceed due to a critical error in an early task, often one that upstream tasks depend on.

Option Analysis:

A. Attention required: This is correct as the playbook has completed, but with partial success and a task requiring review.

B. Upstream_failed: This status is used if a task cannot run because a prerequisite or "upstream" task failed. Since four out of five tasks completed, this is not the case here.

C. Failed: This status would imply that the playbook completely failed, which does not match the scenario where only one task out of five failed.

D. Success: This status would apply if all tasks had completed successfully, which is not the case here.

Conclusion:

Correct Answer: A. Attention required

The playbook status reflects that it completed, but an error occurred in one of the tasks, prompting the administrator to review the failed task.

In the exhibit, the playbook configuration shows the analyst working with the "Attach Data" action within a playbook. Here’s a breakdown of key aspects:

Incident ID: This field is linked to the "Playbook Starter," which indicates that the playbook will attach data to an existing incident.

Attachment: The analyst is configuring an attachment by selecting Run_REPORT with a placeholder ID for report_uuid. This suggests that the report’s UUID will dynamically populate as part of the playbook execution.

Analysis of Options:

Option A - Creating a Trigger Variable:

A trigger variable would typically be set up in the playbook starter or initiation configuration, not within the "Attach Data" action. The setup here does not indicate a trigger, as it’s focusing on data attachment.

Conclusion: Incorrect.

Option B - Creating an Output Variable:

The field Attachment with a report_uuid placeholder suggests that the analyst is defining an output variable that will store the report data or ID, allowing it to be attached to the incident. This variable can then be referenced or passed within the playbook for further actions or reporting.

Conclusion: Correct.

Option C - Creating a Report in the Playbook:

While Run_REPORT is selected, it appears to be an attachment action rather than a report generation task. The purpose here is to attach an existing or dynamically generated report to an incident, not to create the report itself.

Conclusion: Incorrect.

Option D - Creating a SOC Report:

Similarly, this configuration is focused on attaching data, not specifically generating a SOC report. SOC reports are generally predefined and generated outside the playbook.

Conclusion: Incorrect.

Conclusion:

Correct Answer: B. The analyst is trying to create an output variable to be used in the playbook.

The setup allows the playbook to dynamically assign the report_uuid as an output variable, which can then be used in further actions within the playbook.

In the exhibit, the data structure shows a checksum field and a data field with a long, seemingly encoded string. This format is indicative of a file that has been compressed or encoded for storage and transfer.

Export Data Type:

The data field is likely a base64-encoded string, which is commonly used to represent binary data in text format. Base64 encoding is often applied to data that has been compressed (zipped) for easier handling and transfer. The checksum field, with an MD5 hash, provides a way to verify the integrity of the data after decompression.

Option Analysis:

A. The export data type is zipped: Correct. The compressed and encoded format of the data suggests that the export is in a zipped format, allowing for efficient storage and transfer.

B. The playbook is misconfigured: There is no indication of misconfiguration in this exhibit. The presence of the checksum and data fields aligns with standard export practices.

C. The option to include the connector was not selected: There is no evidence in the output to conclude that connectors are missing. Connectors are typically listed separately and would not directly affect the checksum and encoded data structure.

D. Your colleague put a password on the export: There’s no indication of password protection in the exhibit. Password protection would likely alter the data structure, and there would be some mention of encryption.

Conclusion:

Correct Answer: A. The export data type is zipped.

This answer is consistent with the typical use of base64 encoding for compressed (zipped) data exports in FortiAnalyzer.

The requirement here is to construct a SQL query that retrieves logs with specific fields, namely "Source IP" and "Destination Port," for entries where the source IP address matches 10.0.1.10. The correct syntax is essential for selecting, filtering, ordering, and grouping the results as shown in the expected outcome.

Analysis of the Options:

Option A Explanation:

SELECT srcip AS "Source IP", dstport AS "Destination Port": This syntax selects srcip and dstport, renaming them to "Source IP" and "Destination Port" respectively in the output.

FROM $log: Specifies the log table as the data source.

WHERE $filter AND srcip = '10.0.1.10': This line filters logs to only include entries with srcip equal to 10.0.1.10.

ORDER BY dstport DESC: Orders the results in descending order by dstport.

GROUP BY srcip, dstport: Groups results by srcip and dstport, which is valid SQL syntax.

This option meets all the requirements to get the expected results accurately.

Option B Explanation:

WHERE $filter AND Source IP != '10.0.1.10': Uses != instead of =. This would exclude logs from the specified IP 10.0.1.10, which is contrary to the expected result.

Option C Explanation:

The ORDER BY clause appears before the FROM clause, which is incorrect syntax. SQL requires the FROM clause to follow the SELECT clause directly.

Option D Explanation:

The GROUP BY clause should follow the FROM clause. However, here, it’s located after WHERE, making it syntactically incorrect.

Conclusion:

Correct Answer: A. Option A

This option aligns perfectly with standard SQL syntax and filters correctly for srcip = '10.0.1.10', while ordering and grouping as required.

To ensure that reports generated by FortiAnalyzer are automatically sent to an email inbox, you need to set up an output profile for the reports. Output profiles specify where and how reports should be delivered, including the option to send them via email.

Option A - Enable the Option to Email All Reports Under the Mail Server:

The mail server configuration allows FortiAnalyzer to send emails but does not automatically enable email distribution for reports. This setting alone does not specify which reports to send or to whom.

Conclusion: Incorrect.

Option B - Add a mailto:<email address> Option Within the Report Layouts:

Adding an email address within the report layout is not a standard configuration option for report distribution. Report layouts define the format and content of the report but not its distribution method.

Conclusion: Incorrect.

Option C - Enable Email Notification Under the Report Calendar:

The report calendar is used to schedule when reports are generated. While it triggers report generation at specific times, it does not handle email distribution. Emailing reports requires a configured output profile.

Conclusion: Incorrect.

Option D - Enable an Output Profile on the Reports:

An output profile can be configured on FortiAnalyzer to define delivery options, including emailing the report to specified recipients. This setup ensures that every time a report is generated according to the schedule, it is automatically emailed to the configured address.

Conclusion: Correct.

Conclusion:

Correct Answer: D. Enable an output profile on the reports.

Configuring an output profile is the correct way to set up automatic email distribution of generated reports in FortiAnalyzer.
