Free Practice Questions for Ericsson ECP-206 Exam

Within an IGP area, routers advertise information about themselves and relay information delivered by neighbors. This is how link-state routing protocols such as OSPF and IS-IS work. They flood information about the network topology to all routers in the same area or domain. That information is then used to build a complete network connectivity map and to calculate the shortest path to destinations. Routers do not summarize or discard information within an area, unless they are configured to do so by some filtering mechanism. References: Ericsson IP Networking - Routing Protocols, IP Routing: ISIS Configuration Guide - IS-IS Overview and Basic Configuration

MTU mismatch would cause an IS-IS adjacency between two routers to fail. MTU stands for maximum transmission unit, which is the maximum size of a packet that can be transmitted on a link. IS-IS hellos are padded to the full MTU size, partly to allow a router to implicitly communicate its MTU to its neighbors. If two routers have different MTUs on their interfaces, they will not be able to exchange hellos properly, and their adjacency will not form or will be dropped34. To solve this problem, the MTUs on both interfaces must be configured to match.

SEL, context, and SysID are not fields that would cause an IS-IS adjacency failure. SEL stands for selector, which is a one-octet field that identifies the network layer service to which a packet should be sent. For IS-IS routers, the SEL must always be 005. Context is not a field in IS-IS packets, but rather a term used to describe the scope of routing information in different levels or areas6. SysID stands for system identifier, which is a six-octet field that uniquely identifies a router within an area. SysID does not have to match between two routers for them to form an adjacency7.

References: MTU Mismatch Problem in IS-IS - Cisco, IS-IS adjacency is not formed due to MTU mismatch - Cisco Community, IS-IS NSAP address - Cisco Community, Understanding IS-IS Routing Contexts - Juniper Networks, IS-IS - Nokia

The device that will fragment IPv6 packets is the source host. Fragmentation is a process of dividing a large packet into smaller pieces that can fit the maximum transmission unit (MTU) of the network link. In IPv4, fragmentation can be performed by either the source host or any intermediate router along the path. However, in IPv6, fragmentation is only allowed at the source host, and routers are not allowed to fragment packets. This reduces the processing overhead and complexity at routers and avoids potential fragmentation attacks. If a router receives an IPv6 packet that is too large for the next-hop link, it will drop the packet and send an ICMPv6 Packet Too Big message back to the source host56.

References: IPv6 address - Wikipedia, IPv6 Fragmentation - Cisco

The next-hop to reach the host 192.168.1.129 is 10.126.131.250. This can be determined by looking at the routing table in the exhibit. The host 192.168.1.129 falls within the range of the network 192.168.1.64/26, which has a next-hop of 10.126.131.250. References: Ericsson IP Networking - IP Addressing, Software Installation and Upgrade Overview (Junos OS)

Two roles of the DHCP protocol in a network are:

It is used by hosts to obtain the IP address and other parameters from the DHCP server. DHCP stands for Dynamic Host Configuration Protocol, which is a protocol that provides automatic and centralized management of IP addresses and other network configuration parameters for devices connected to a network. A host that needs an IP address can send a request to a DHCP server, which will assign an available IP address from a pool and lease it to the host for a certain period of time34.

It is used to inform hosts about the default gateway. The default gateway is the IP address of the router that connects the host to other networks. The default gateway is one of the parameters that can be delivered by the DHCP server to the host, along with other parameters such as subnet mask, DNS server, domain name, etc. The host can use the default gateway to send packets to destinations outside of its local network34.

References: What Is DHCP? (Dynamic Host Configuration Protocol) - Lifewire, Dynamic Host Configuration Protocol - Wikipedia

Spanning-Tree is used for Ethernet loop avoidance. Spanning-Tree is a protocol that prevents loops in Ethernet networks by creating a logical tree topology of the network switches. Spanning-Tree blocks some of the redundant links between switches to ensure that there is only one active path between any two nodes in thenetwork. Spanning-Tree also detects and recovers from link failures by activating alternative paths when needed56.

References: Network loops and loop avoidance - Medium, Spanning Tree Protocol - Wikipedia

The router function that advertises external routes in OSPF is ASBR, which stands for Autonomous System Boundary Router. An ASBR is a router that connects an OSPF domain to another routing domain, such as another OSPF domain or a different routing protocol domain. An ASBR can redistribute routes from other routing domains into OSPF as external routes, which are carried in type 5 or type 7 LSAs. External routes have two types: E1 and E2. E1 routes include the cost from the ASBR to the destination, while E2 routes only include the cost advertised by the ASBR34.

References: OSPF External Routes ⋆ IpCisco, OSPF External Route selection algorithm - Cisco Community

A label-edged router (LER) is a PE router. A PE router is a provider edge router, which is a router that connects an MPLS network to a customer network. A LER is a term used in MPLS to describe a router that resides at the ingress and egress points of an MPLS network, handling both labelled and unlabelled packets. A LER performs label operations such as adding, removing, or swapping labels on packets entering or leaving the MPLS network34.

References: What is Label Edge Router (LER)? - Definition from Techopedia, LER - Label Edge Router - Mpirical
