Free Practice Questions for Cisco 300-425 Exam

 When designing a backhaul link, the mesh AP role should be set to ‘bridge’ to enable it to connect separate network segments or extend coverage to remote areas.

 In an office environment with cubicles, signal propagation is most commonly affected by absorption. This is because the materials used in cubicle walls, such as fabric and other dense substances, tend to absorb the radio frequency (RF) signals used in WLANs, leading to attenuation.

 In a Layer 1 passive wireless site survey, the chart that indicates the ratio of interference present during the duration of the capture in the 2.4 GHz spectrum is typically a Duty Cycle chart or an Interference chart. These charts display the percentage of time that energy, possibly from interfering sources, is present on a channel. The correct answer would show fluctuations in signal levels over time, highlighting periods where interference might be affecting the channel’s clarity.

Jammers are non-Wi-Fi interferers that can be identified by Metageek Chanalyzer. They intentionally disrupt wireless communications by emitting radio frequencies that interfere with Wi-Fi signals. Chanalyzer is designed to detect such patterns of interference.

https://www.metageek.com/training/resources/wifi-and-non-wifi-interference

The Voice Readiness tool within Cisco Prime Infrastructure is designed to assess the wireless network’s ability to support voice services, including VoIP. It evaluates various factors such as signal strength, noise levels, and coverage to ensure that the wireless network can handle the quality of service requirements needed for voice communications.

In Cisco WLC version 8, the need for separate WPlus licenses has been eliminated as all features that were previously part of the WPlus license are now included in the Base license. This consolidation simplifies licensing management and ensures that customers have access to all necessary features without requiring additional licenses. References := (CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide Premium Edition and Practice)

For a wireless voice deployment, Cisco recommends that the edge of the cell should have a signal strength of -67 dBm to ensure reliable voice quality and seamless roaming capabilities.

When a client roams between two access points (APs) that are registered to different controllers with interfaces in the same client subnet, the controllers will exchange mobility control messages over UDP port 16666. This is in accordance with the Designing Cisco Enterprise Wireless Networks (ENWLSD) guidelines. The purpose of these messages is to ensure seamless roaming, where the client’s session and authentication state are transferred from one controller to another without requiring re-authentication or re-association by the client. The mobility control messages facilitate the coordinated transfer of the client database entry from the original controller to the new one, maintaining a consistent experience for the user.
