Free Practice Questions for Avaya 71301X Exam

With Dynamic Licensing configured in the Avaya Session Border Controller for Enterprise (ASBCE), the ASBCE will issue a request to the WebLM server to allocate additional licenses based on the Fetch Count value when the percentage of free (available) standard sessions licenses drops below 30% (Low Watermark). Dynamic Licensing is a feature that allows the ASBCE to dynamically allocate and release licenses from a pool of licenses managed by the WebLM server. The Fetch Count value is a parameter that specifies how many licenses are requested from the WebLM server at a time. The Low Watermark value is a parameter that specifies the threshold percentage of free licenses that triggers a request for more licenses from the WebLM server. The High Watermark value is a parameter that specifies the threshold percentage of free licenses that triggers a release of unused licenses to the WebLM server

In the Avaya Session Border Controller for Enterprise (ASBCE), the state of a Network Interface, after the deployment, is Disabled. A Network Interface is a logical interface that represents a physical port on the ASBCE server. A Network Interface can be configured with an IP address, subnet mask, gateway, and VLAN ID. After the deployment of the ASBCE server, the Network Interfaces are in a Disabled state by default. To enable a Network Interface, you need to use the ASBCE web interface or CLI and configure the interface parameters. You also need to assign the interface to a Zone, which is a logical grouping of interfaces that defines the security and routing policies for the ASBCE server

The Avaya Spaces Calling extension is a softphone that provides calling features to users of Avaya Spaces by leveraging their existing Avaya infrastructure. This extension can be used alongside the Avaya Spaces web application or desktop client to make and receive audio calls through the Avaya Aura® Web Gateway (AAWG). To add the Avaya Spaces Calling extension, you need to have internet access and use the Google Chrome browser to open the Chrome Web Store. Then, you need to search for the Avaya Spaces Calling extension and click on the Add to Chrome button. The extension will be installed and added to your Chrome browser. You can then use the extension icon in the browser toolbar to access the Avaya Spaces Calling settings and features12

When installing the identity certificate and encryption key files on the Avaya Session Border Controller for Enterprise (ASBCE), you need to follow this rule: The filename of the identity certificate (.pem or .crt file) must be different from the filename of the encryption key (.key file). An identity certificate is a file that contains information about the identity and public key of an entity, such as a server or an endpoint. An encryption key is a file that contains information about the private key of an entity, which is used to encrypt and decrypt data. The identity certificate and encryption key files are obtained from a Certificate Authority (CA) or generated by yourself using tools such as OpenSSL. When installing these files on the ASBCE server, you need to make sure that they have different filenames, otherwise they will overwriteeach other and cause errors. For example, you can name them as sbce-cert.pem and sbce-key.key respectively.

The Avaya Workplace client is an application that provides voice, video, messaging, presence, and collaboration features for users. The Avaya Workplace client uses the XMPP protocol to communicate with the Avaya Aura® Presence Services snap-in on the Avaya Breeze® server. The Presence Services snap-in delivers the presence related messages to the Avaya Workplace client from the Avaya Breeze® Security Module (SM100) interface. The SM100 is a component of the Avaya Breeze® server that provides security and encryption functions for SIP signaling and media. The SM100 interface uses port 5222 for client-to-server XMPP connections.

The Avaya Session Border Controller for Enterprise (ASBCE) requires licenses to support different types of services, such as SIP Trunking or Remote Worker. The ASBCE licenses are based on the number of concurrent sessions that are handled by the ASBCE server. There are two types of licenses: standard services licenses and advanced services licenses. A standard services license is required for each SIP Trunking session, which is a session between the ASBCE server and a SIP service provider. An advanced services license is required for each Remote Worker session, which is a session between the ASBCE server and a remote endpoint, such as an IP phone or a softphone. Therefore, if the customer plans to have 50 SIP Trunks and100 Remote Workers supported by the ASBCE, they will need 50 standard services licenses and 100 advanced services licenses.

When registering as a Remote Worker via the Avaya Session Border Controller for Enterprise (ASBCE), you should configure the ASBCE External (Public) Interface IP address allocated for Remote Workers in the Server List of the Avaya one-X® Communicator. The ASBCE External (Public) Interface is the interface that connects the ASBCE server to the public Internet and allows communication with external entities, such as Remote Workers or SIP service providers. The ASBCE server acts as a proxy for the Remote Workers and handles the SIP registration and call signaling with the Avaya Aura® Session Manager (SM). Therefore, you need to specify the ASBCE External (Public) Interface IP address as the SIP server address in the Avaya one-X® Communicator settings

Before you can begin configuring SIP Trunking, the status that all the Avaya Session Border Controller for Enterprise (ASBCE) components / devices should show on the Device Management screen is Ready. The Device Management screen is a web interface that allows you to view and manage the ASBCE components / devices, such as EMS (Element Management System), SBC (Session Border Controller), or HCA (High Capacity Appliance). The Device Management screen displays information such as device name, management IP, version, status, reboot, and shutdown for each component / device. The status indicates the operational state of the component / device, which can be one of these values: Provisioned, Commissioned, Registered, or Ready. The Ready status means that the component / device is fully operational and ready to handle traffic. Therefore, before configuring SIP Trunking, you should make sure that all the ASBCE components / devices have a Ready status on the Device Management screen.

The Survivable Communication Manager (CM) is configured on the System Manager (SMGR) as a Managed Element. A Managed Element is an entity that can be managed by SMGR, such as Communication Manager, Session Manager, Presence Services, or Breeze Platform. A Survivable CM is a Communication Manager instance that provides local call processing and trunking capabilities for remote sites or branches in case of a WAN outage or loss of connectivity with the core servers. A Survivable CM can be deployed on an S8300D server or on an external server such as Dell R620/R630 or HP DL360 G8/G9. To configure a Survivable CM as a Managed Element on SMGR, you need to specify its name, type, IP address, login credentials, and security settings56

When integrating the Application Enablement Services (AES) with the Avaya Aura® Communication Manager (CM), you need to configure a Switch Password in two places: on the “cti-link” screen in CM, and in “Switch Connections” on AES. TheSwitch Password is a password that is used to authenticate the communication between CM and AES. CM and AES use a protocol called Adjunct Switch Application Interface (ASAI) to exchange information and commands related to Computer Telephony Integration (CTI) applications. ASAI requires a Switch Password to establish a secure connection between CM and AES. To configure the Switch Password, you need to use these two screens:

The “cti-link” screen in CM: This is a screen that allows you to create and manage CTI links, which are logical connections between CM and CTI servers, such as AES. You can access this screen using the System Access Terminal (SAT) interface of CM. On this screen, you need to specify a name, number, type, and password for each CTI link. The password is the Switch Password that will be used by CM to authenticate AES.

The “Switch Connections” screen on AES: This is a screen that allows you to create and manage switch connections, which are logical connections between AES and switches, such as CM. You can access this screen using the web interface of AES. On this screen, you need to specify a name, IP address, port, type, and password for each switch connection. The password is the Switch Password that will be used by AES to authenticate CM.
