A company deploys a software solution on Amazon EC2 instances that are in a clusterplacement group. The solution's UI is a single HTML page. The HTML file size is 1,024 bytes. The software processes files that exceed 1,024 MB in size. The software shares files over the network to clients upon request. The files are shared with the Don't Fragment flag set. Elastic network interfaces of the EC2 instances are set up with jumbo frames.

The UI is always accessible from all allowed source IP addresses, regardless of whether the source IP addresses are within a VPC, on the internet, or on premises. However, clients sometimes do not receive files that they request because the files fail to travel successfully from the software to the clients.

Which options provide a possible root cause of these failures? (Choose two.)

A.

The source IP addresses are from on-premises hosts that are routed over AWS Direct Connect.

B.

The source IP addresses are from on-premises hosts that are routed over AWS Site-to-Site VPN.

C.

The source IP addresses are from hosts that connect over the public internet.

D.

The security group of the EC2 instances does not allow ICMP traffic.

E.

The operating system of the EC2 instances does not support jumbo frames.

A logistics company has multiple VPCs in an AWS Region. The company uses a transit gateway to connect the VPCs. The company has several on-premises offices that connect to the transit gateway by using AWS Site-to-Site VPN connections over the internet. The company has configured one transit gateway VPN attachment for each office.

Route propagation is enabled on all route tables. Each Site-to-Site VPN connection uses two tunnels in an active-passive configuration. The company configured each office with appropriate static routes on both the Site-to-Site VPN connection and the office’s customer gateway.

The company wants to use both IPsec tunnels of every office to maximize the overall VPN connection bandwidth.

Which design changes are necessary to meet these requirements?

A.

Create an AWS Transit Gateway Connect attachment for each office Use the existing VPN attachments as the transport for the new Connect attachments. Set up a Generic Routing

Encapsulation (GRE) tunnel on each customer gateway that terminates on the Connect attachment for each office. Move the static routes from the transit gateway VPN attachment to the customer gateway for the transit gateway Connect attachment.

B.

Enable equal-cost multi-path (ECMP) routing on the transit gateway. Ensure ECMP is supported by and enabled on the customer gateways. Enable ECMP on the Site-to-Site VPN connection. Ensure static routes on the customer gateways have equal metrics and administrative distance.

C.

Enable equal-cost multi-path (ECMP) routing on the transit gateway. (Ensure ECMP is supported by and enabled on the customer gateways. Change the routing configuration between the transit gateway and the customer gateways from static routing to BGP. Remove related static routes from the customer gateways.

D.

Enable equal-cost multi-path (ECMP) routing on the transit gateway. Ensure ECMP is supported by and enabled on the customer gateways. Change the routing configuration between the transit gateway and the customer gateways from static routing to BGP. Ensure the customer gateway applies the correct community strings to give the transit gateway the ability to perform ECMP forwarding.

A company is using Amazon Route 53 Resolver DNS Firewall in a VPC to block all domains except domains that are on an approved list. The company is concerned that if DNS Firewall is unresponsive, resources in the VPC might be affected if the network cannot resolve any DNS queries. To maintain application service level agreements, the company needs DNS queries to continue to resolve even if Route 53 Resolver does not receive a response from DNS Firewall.

Which change should a network engineer implement to meet these requirements?

A.

Update the DNS Firewall VPC configuration to disable fail open for the VPC.

B.

Update the DNS Firewall VPC configuration to enable fail open for the VPC.

C.

Create a new DHCP options set with parameter dns_firewall_fail_open=false. Associate the new DHCP options set with the VPC.

D.

Create a new DHCP options set with parameter dns_firewall_fail_open=true. Associate the new DHCP options set with the VPC.

An AWS CloudFormation template is being used to create a VPC peering connection between two existing operational VPCs, each belonging to a different AWS account. All necessary components in the ‘Remote’ (receiving) account are already in place.

The template below creates the VPC peering connection in the Originating account. It contains these components:

AWSTemplateFormation Version: 2010-09-09

Parameters:

Originating VCId:

Type: String

RemoteVPCId:

Type: String

RemoteVPCAccountId:

Type: String

Resources:

newVPCPeeringConnection:

Type: ‘AWS::EC2::VPCPeeringConnection’

Properties:

VpcdId: !Ref OriginatingVPCId

PeerVpcId: !Ref RemoteVPCId

PeerOwnerId: !Ref RemoteVPCAccountId

Which additional AWS CloudFormation components are necessary in the Originating account to create an operational cross-account VPC peering connection with AWS CloudFormation? (Select two.)

A.

Resources:NewEC2SecurityGroup:Type: AWS::EC2::SecurityGroup

B.

Resources:NetworkInterfaceToRemoteVPC:Type: “AWS::EC2NetworkInterface”

C.

Resources:newEC2Route:Type: AWS::EC2::Route

D.

Resources:VPCGatewayToRemoteVPC:Type: “AWS::EC2::VPCGatewayAttachment”

E.

Resources:newVPCPeeringConnection:Type: ‘AWS::EC2VPCPeeringConnection’PeerRoleArn: !Ref PeerRoleArn

A company has a data center in the us-west-1 Region with a 10 Gbps AWS Direct Connect dedicated connection to a Direct Connect gateway. There are two private VIFs from the same data center location in us-west-1 that are attached to the same Direct Connect gateway.

VIF 1 advertises 172.16.0.0/16 with an AS PATH attribute value of 65000. VIF 2 advertises 172.16.1.0/24 with an AS PATH attribute value of 65000 65000 65000.

How will AWS route traffic to the data center for traffic that has a destination address within the 172.16.1.0/24 network range?

A.

AWS will route all traffic by using VIF 1.

B.

AWS will route all traffic by using VIF 2.

C.

AWS will use both VIFs for routing by using a round-robin policy.

D.

AWS will use flow control to balance the traffic between the two VIFs.

A company hosts application servers on premises and on Amazon EC2 instances in a VPC. The application servers access data that is hosted in an Amazon S3 bucket through the public internet. The EC2 instances in the VPC use an AWS Site-to-Site VPN for connectivity with the on-premises application servers.

New company regulations state that all traffic between the application servers and the S3 bucket must remain private and must not use public IP addresses.

Which solution will meet these requirements MOST cost-effectively?

A.

Configure an S3 gateway endpoint Modify the route table with the appropriate route for the endpoint. Access the S3 bucket through the gateway endpoint from the EC2 instances.

B.

Configure an S3 interface endpoint. Update the on-premises servers and EC2 instances to use the interface endpoint DNS name to access the S3 bucket.

C.

Configure an S3 interface endpoint. Update the on-premises servers to use the interface endpoint DNS name to access the S3 bucket. Configure an S3 gateway endpoint. Modify the route table so that the EC2 instances use the gateway endpoint.

D.

Configure an S3 gateway endpoint. Modify the route table with the appropriate route for the endpoint. Use an S3 bucket policy to restrict access to the gateway endpoint. Configure a proxy server fleet behind a Network Load Balancer in the VPC so that the on-premises servers can access the S3 bucket.

A company operates in multiple AWS Regions. The company has deployed transit gateways in each Region. The company uses AWS Organizations to operate multiple AWS accounts in one organization.

The company needs to capture all VPC flow log data when a new VPC is created. The company needs to send flow logs to a specific Amazon S3 bucket.

Which solution will meet these requirements with the LEAST administrative effort?

A.

Update IAM permissions for each user to include a condition that ensures users cancreate VPCs only when VPC Flow Logs is enabled and configured correctly.

B.

Create a custom AWS Config rule with automatic remediation that verifies VPC Flow Logs is enabled and configured correctly. Apply the AWS Config rule to the organization.

C.

Enable VPC Flow Logs on each transit gateway. Configure VPC Flow Logs to send flow logs to the specified S3 bucket.

D.

Deploy a serverless application that uses AWS CloudTrail to monitor for VPC creation events in each account. Configure the application to apply the correct VPC Flow Logs configuration.

A company operates in the us-east-1 Region and the us-west-1 Region. The company is designing a solution to connect an on-premises data center to the company's AWS environment in us-east-1. The solution uses two AWS Direct Connect connections.

Traffic from us-west-1 to the data center needs to traverse the Direct Connect connections. A network engineer needs to set up active-passive functionality across the two Direct Connect connections by using a Direct Connect gateway to influence inbound traffic from VPCs that are in us-west-1 to the data center.

Which solution will meet these requirements?

A.

At the data center, set the local preference for the primary connection to be higher than the local preference for the secondary connection.

B.

Use AS path prepending to set the AS path on the primary connection to be longer than the AS path on the secondary connection.

C.

Use local preference BGP community tags to apply the 7224:7300 local preference BGP community tag to the prefixes for the primary connection. Apply the 7224:7100 local preference BGP community tag to the prefixes for the secondary connection.

D.

Use local preference BGP community tags to apply the 7224:9300 local preference BGP community tag to the prefixes for the primary connection. Apply the 7224:9100 local preference BGP community tag to the prefixes for secondary connection.

AnyCompany deploys and manages networking resources in its AWS network account, named Account-A. AnyCompany acquires Example Corp, which has an application that runs behind an Application Load Balancer (ALB) in Example Corp's AWS account, named Account-B.

Example Corp needs to use AWS Global Accelerator to create an accelerator to publish the application to users. AnyCompany's networking team will manage the accelerator.

Which solution will meet these requirements with the LEAST management overhead?

A.

Create an accelerator in Account-В. Use a cross-account role from Account-A to grant the networking team access to manage the accelerator.

B.

Deploy a Network Load Balancer (NLB) in Account-A to route traffic to the ALB in Account-В. Create an accelerator, and set the NLB as the endpoint in Account-A.

C.

Create a cross-account Global Accelerator attachment in Account-В for the Account-A principal. Create an accelerator in Account-A by using the shared attachment.

D.

Create an accelerator in Account-A. Use AWS Resource Access Management (AWS RAM) to share the accelerator with Account-В. Associate the ALB in Account-В with the accelerator in Account-A.

A company has VPCs in the us-east-1 Region that are connected to each other through a transit gateway. A network engineer needs to establish an AWS Direct Connect connection between the company's on-premises data center and the transit gateway for the migration of a workload.

The Direct Connect connection is UP according to the ConnectionState metric in Amazon CloudWatch. However, the VIF is DOWN. The network engineer has verified the transit VIF and BGP configurations on the on-premises router and has found no issues. However, the network engineer is unable to ping the Amazon peer IP address.

Which combination of steps should the network engineer take to troubleshoot this issue? (Choose three.)

A.

Verify that the correct IP address and subnet mask are in use for the subinterface on the router.

B.

Ensure that VLAN trunking is disabled on the router.

C.

Verify that the router has a MAC address entry from the AWS endpoint in the Address Resolution Protocol (ARP) table.

D.

Verify that the optical signal that is received over the cross connect is optimal.

E.

Ensure that the correct VLAN tag is applied on the subinterface configuration on the router.

F.

Ensure that TCP port 179 is not being blocked at the on-premises router.
