Free Practice Questions for ASQ CQE Exam

When several units from a random sample are found to be defective, the immediate next action should be to segregate the defective units. This step is crucial to prevent defective units from being mixed with non-defective units, ensuring that they do not reach customers or proceed further in the production process. Segregating defective units helps in identifying the extent of the issue and facilitates further investigation and corrective actions.

The diagram shown is typical of an interaction plot used in the analysis of designed experiments.

Confounded:

Confounding occurs when the effects of two factors cannot be separated. The diagram does not indicate this.

Replicated:

Replication refers to repeating the experiment or conditions multiple times to ensure reliability, not depicted here.

Show Randomization:

Randomization refers to the random assignment of treatments to experimental units. The plot does not indicate this.

Show Interaction:

Interaction occurs when the effect of one factor depends on the level of another factor.

The crossing lines in the plot indicate that the response to Factor A changes depending on the level of Factor B, demonstrating an interaction between the two factors.

References: Design of experiments (DOE) and statistical analysis texts.

The constant failure rate per hour is calculated as the inverse of the mean time between failures (MTBF). Given an MTBF of 200 hours: Failure rate (λ) = 1 / MTBF = 1 / 200 = 0.005

When establishing a system for the classification of defects, it is crucial to consider the relative seriousness of the defects. This involves evaluating the potential impact of each type of defect on the end-user and the product's performance. The classification typically divides defects into categories such as critical, major, and minor, based on their severity and potential consequences.

References:

"Quality Control Handbook" by J.M. Juran.

ISO 2859-1:1999, "Sampling procedures for inspection by attributes"

Destructive test methods are those that cause damage or permanent alteration to the specimen being tested.

Radiography:

Non-destructive method using X-rays or gamma rays to view the internal structure.

Acoustic Emission:

Non-destructive technique detecting transient elastic waves produced by a sudden redistribution of stress.

Corrosion:

Destructive process where materials are degraded due to chemical reactions with their environment.

Magnetic Particle:

Non-destructive method using magnetic fields to detect surface and near-surface discontinuities.

Corrosion testing inherently destroys or alters the material being tested, categorizing it as a destructive method.

References: Materials testing standards and non-destructive testing (NDT) handbooks.

To ensure traceability from design and production through to end-user receipt and use, a company must develop a robust product identification system. This system involves assigning unique identifiers to each product or batch, which can be tracked throughout the entire supply chain. This allows for effective tracking of production history, quality control, and accountability in the event of product issues or recalls.

References:

"Traceability in the Food and Feed Chain" by IFSQN.

ISO 9001:2015, Quality Management Systems – Requirements

Risk describes the combination of the severity and probability of occurrence of harm. In the context of quality management, risk assessment involves evaluating both how severe the potential harm could be and the likelihood of it occurring, to manage and mitigate potential failures effectively.References:

Failure Mode and Effect Analysis (FMEA) by ASQ Quality Press.

ISO 31000: Risk Management Guidelines.

The expected number of rejects per sample can be calculated using the reject rate and the sample size. Given a reject rate of 6% (or 0.06) and a sample size of 5:

Expected number of rejects per sample = 0.06 * 5 = 0.3

References:

Montgomery, D.C. (2009). Introduction to Statistical Quality Control. Wiley.

ASQ. (n.d.). Basic Quality Tools. Retrieved from https://asq.org/quality-resources/basic-quality-tools

In geometric dimensioning and tolerancing (GD&T), the symbol shown in the image is used to indicate a datum target point. This symbol is employed to designate specific locations on a part that are used as reference points for measurements. Datum targets are essential for ensuring accurate and repeatable measurements, particularly in complex assemblies where precision is crucial.

Datum Target Point: A specific point on a part that serves as a reference for measurement or manufacturing. Datum target points are critical for establishing a reference frame for the part's geometry.

References:

ASME Y14.5-2009 - Geometric Dimensioning and Tolerancing Standard.

Foster, L. W. (2010). Geometric Dimensioning and Tolerancing for Mechanical Design 2/E. McGraw-Hill Education.
