Free Practice Questions for Huawei H12-821_V1.0 Exam

Comprehensive and Detailed Step-by-Step Explanation:

1. Understanding the AS-Path Filter:

The as-path-filter command is used in BGP to filter routes based on the AS_PATH attribute.

In this configuration:

The filter si is defined with the regular expression _65500$.

The _65500$ expression specifies that the AS_PATH must end with 65500, meaning that the route's last hop must have passed through AS 65500.

2. Option Analysis:

Option A: It accepts only the routes whose AS_Path contains AS 65500.

Incorrect.

The _65500$ filter specifically matches routes where AS 65500 is the last AS in the AS_PATH. A route may contain AS 65500 somewhere in the middle of the AS_PATH but will not match this filter unless it is the last AS.

Option B: It accepts only the routes originated from AS 65500.

Incorrect.

Routes that originate from AS 65500 have an AS_PATH that starts with 65500. However, the filter _65500$ only matches routes where AS 65500 is the last AS, not the first AS.

Option C: It accepts only the routes that last pass through AS 65500.

Correct.

The _65500$ filter ensures that the AS_PATH ends with 65500. This means that the route must have last passed through AS 65500 before being received by the local BGP router.

Option D: It accepts only the routes forwarded by AS 65500.

Incorrect.

While AS 65500 may forward the route, this is not what the filter _65500$ specifically checks for. It only ensures that AS 65500 is the last AS in the AS_PATH.

3. Summary:

The as-path-filter with _65500$ accepts only the routes where AS 65500 is the last AS in the AS_PATH.

Huawei HCIA-Datacom Study Guide, Chapter "BGP Filtering Mechanisms"

RFC 4271: Border Gateway Protocol 4 (BGP-4)

Comprehensive and Detailed Step-by-Step Explanation:

IGMPv1 Querier Selection:

In IGMPv1, there is no built-in querier election mechanism. Querier selection depends on the multicast routing protocol (e.g., PIM).

IGMPv2 and IGMPv3 Querier Selection:

In IGMPv2 and IGMPv3, the router interface with thelargest IP addressin the multicast group is selected as the querier.

Correct Statement:

The statement accurately describes the querier selection mechanisms in IGMP versions.

IGMPv1 supports general queries but does not define a Leave message. IGMPv2 introduces the Leave message type, which allows hosts to notify routers when they wish to leave a multicast group, improving efficiency. These distinctions align with the functionality of IGMP versions ​.

The Forwarding Information Base (FIB) is derived from the router's routing table and contains the exact forwarding entries used to route packets. It directly guides packet forwarding decisions by matching incoming packets with the correct output interface or next-hop address ​.

Comprehensive and Detailed Step-by-Step Explanation:

BGP Router ID Selection Rules:

If a router ID is not manually configured:

The largest loopback address is selected as the router ID.

If no loopback interfaces exist, the largest active physical interface address is selected.

Default Behavior:

This ensures that a stable and unique router ID is chosen automatically, even without manual configuration.

Let's break it down step by step based on Huawei's routing protocol behavior:

R1imports thedirect route 10.1.1.0/24intoOSPF.

This route is advertised byR1 to R2 and R3viaOSPF.

BothR2 and R3are runningIS-IS, andbidirectional route redistributionis configured between OSPF and IS-IS.

R2 and R3 bothre-advertisethe OSPF-learned route into IS-IS and then potentiallyre-learnit back from the IS-IS domain, causingredistribution loopsunless properly controlled.

Now, the question focuses onR3’s routing table:

R3 already learns the routedirectly via OSPFfrom R1.

It also learns the same route again viaIS-ISfrom R2 (looped back due to bidirectional redistribution).

Reference from Huawei HCIP-Datacom-Core Technology Study Guide:

“OSPF ASE routes are assigned a default preference of 150. If a route is redistributed from another protocol (like IS-IS) into OSPF, and then re-learned, it is considered an ASE route.”(Chapter: OSPF Advanced Features – Section: Route Redistribution Behavior)

Comprehensive and Detailed in-depth Step-by-Step Explanation:

TheNetwork Entity Title (NET)is a unique identifier assigned to an IS-IS router. It is derived from theNetwork Service Access Point (NSAP)address and consists of the following components:

Area Address:

Identifies the area in which the router resides.

Multiple routers in the same IS-IS area must have the same area address.

System ID:

Uniquely identifies the router within the IS-IS area.

The System ID is typically derived from the router's loopback IP address or another unique value.

SEL (Selector Field):

The SEL field is always set to00for IS-IS NETs.

The NET is used by IS-IS for route calculation and to identify the router within the IS-IS domain. Therefore, the statement isTRUE.

The LS age field in OSPF LSAs (Link State Advertisements) is measured in seconds and increments over time in the Link State Database (LSDB). If the LS age reaches the LSRefreshTime (30 minutes), the router that originated the LSA must regenerate it to keep the LSA valid in the network. Options C and B are incorrect since LS age does not decrease, and only the originator regenerates LSAs ​.

The CAPWAP heartbeat detection interval is typically multiplied by a predefined factor to determine the switchover time. For instance, in Huawei devices, a common default is three missed heartbeats before a switchover is triggered. With a detection interval of 20 seconds, the switchover occurs after 60 seconds (20 x 3). This ensures that transient network issues do not cause unnecessary switchovers ​.

Comprehensive and Detailed Step-by-Step Explanation:

Default Next Hop Behavior in BGP:

Locally Originated Routes (A):The next hop is set to the advertising router's interface IP address.

Routes Received from EBGP (B):The next hop is not changed when these routes are advertised to IBGP peers. (This makes Option B false.)

Routes Advertised to EBGP (C):The next hop is set to the interface IP address of the advertising router.

Routes Advertised Between IBGP Peers (D):The next hop is not modified by default.

Incorrect Statement:

Option B is incorrect because the next hop of a non-labeled route received from an EBGP peer is not changed when it is advertised to IBGP peers.
