Free Practice Questions for Huawei H12-811_V1.0 Exam

An access port is a switch port assigned to a single VLAN and used to connect end devices (such as PCs or printers).

Access ports do not send VLAN tags. They remove the VLAN tag before forwarding frames to the connected device because most end devices do not support VLAN tagging.

Option A (Incorrect): Tagged frames are sent only by trunk ports, not access ports.

Option B (Correct): The access port strips the VLAN tag before forwarding the frame to ensure compatibility with non-VLAN-aware devices.

Option C (Incorrect): VLAN tags are not exchanged between inbound and outbound ports.

Option D (Incorrect): The access port does not attach PVID information to the frame when sending it out.

Thus, the correct answer is B.

OSPFv1 (B): Was an experimental version, not widely used.

OSPFv2 (C): Used for IPv4 networks, does not support IPv6.

OSPFv3 (D): Specifically designed for IPv6 networks and includes additional features like security and address scope handling.

OSPFv4 (A): This version does not exist.

Thus, the correct answer is D (OSPFv3).

Detailed Explanation:

Option B: OSPF supports triggered updates, allowing routing tables to be updated only when changes occur, conserving bandwidth.

Option D: OSPF supports area division, which is essential for optimizing large networks and limiting the scope of link-state advertisements.

Option A is incorrect because OSPF calculates the shortest path based on cost, not hop count.

Option C is incorrect; OSPF prevents routing loops by maintaining a loop-free topology through its link-state database.

(Reference: HCIA-Datacom Training Material, OSPF Features)

TPID (Tag Protocol Identifier) is a field in the VLAN tag that identifies 802.1Q-tagged frames.

The correct TPID value for 802.1Q is 0x8100.

0x9100 (B) is used for Q-in-Q (double tagging).

0x7200 (A) and 0x8200 (D) are incorrect values.

Thus, the correct answer is C (0x8100).

Detailed Explanation:When bridge priorities are identical, STP elects the switch with the lowest MAC address as the root. Here, Switch B has the lowest MAC address (00-e0-fc-00-00-10), making it the root switch. (Reference: HCIA-Datacom Training Material, STP Root Bridge Election)

In OSPF, the "Full" state signifies that the neighbor relationship has been fully established, with both routers synchronized and their LSDBs updated. This state is achieved after exchanging and acknowledging Link State Advertisements (LSAs) between the neighbors, marking the completion of OSPF adjacency​.

Comprehensive and Detailed Explanation:

The TTL field is 8 bits long, allowing values from 0 to 255 (A is correct).

The TTL prevents routing loops by discarding packets with TTL=0 (B is correct).

Each Layer 3 device (router) that forwards the packet decrements TTL by 1 (C is correct).

If TTL reaches zero, the router drops the packet and sends an ICMP Time Exceeded message.

✅ Reference: HCIA-Datacom Network Principles Guide – IP Packet Structure

To determine which statements are true, we need to analyze the VLAN configurations on the Huawei switch (SWA) as shown in the diagram and configuration details. We’ll evaluate each client’s VLAN membership and verify the correctness of the VLAN assignment commands based on Huawei switch configuration principles, as outlined in HCIA Datacom documentation. Let’s break it down step by step:

Understanding VLAN Assignment Types on Huawei Switches:

Huawei switches support different port link types for VLAN assignment:

Access Port: Carries traffic for a single VLAN (untagged). Typically used for end devices like PCs.

Trunk Port: Carries traffic for multiple VLANs (tagged, except for the native VLAN, which is untagged). Typically used for interconnecting switches.

Hybrid Port: Similar to a trunk port but can carry untagged traffic for specific VLANs, often used for both end devices and inter-switch links. It can tag or untag traffic based on configuration.

Additionally, Huawei supports MAC address-based VLAN assignment (using the mac-vlan command), which assigns VLAN membership based on a device’s MAC address, overriding port-based VLAN settings.

Analyzing the Configuration for Each Client:Let’s examine the configuration details for each interface connected to the clients and verify the VLAN assignments:

Client 1 (connected to GigabitEthernet0/0/1):

Configuration:

text

WrapCopy

vlan 10

#

interface GigabitEthernet0/0/1

port link-type access

port default vlan 10

The port is configured as an access port with port link-type access and assigned to VLAN 10 using port default vlan 10.

Access ports carry untagged traffic for a single VLAN, so Client 1 belongs to VLAN 10.

The commands are correct for an access port assignment to VLAN 10.

Statement C (“Client 1 belongs to VLAN 10, and the commands for VLAN assignment on the switch are correct”) is true.

Client 2 (connected to GigabitEthernet0/0/2):

Configuration:

text

WrapCopy

vlan 20

mac-vlan mac-address 0022-0022-0022 priority 0

#

interface GigabitEthernet0/0/2

port hybrid untagged vlan 20

mac-vlan enable

The port is configured as a hybrid port with port link-type hybrid and set to carry untagged traffic for VLAN 20 using port hybrid untagged vlan 20.

Additionally, mac-vlan mac-address 0022-0022-0022 priority 0 and mac-vlan enable are configured, indicating MAC address-based VLAN assignment for a device with MAC address 0022-0022-0022.

However, the diagram does not specify the MAC address of Client 2. If Client 2’s MAC address is not 0022-0022-0022, the MAC-VLAN assignment does not apply, and the port’s default VLAN (VLAN 20, untagged) determines its membership.

If Client 2 has MAC address 0022-0022-0022, it would belong to the VLAN specified by the mac-vlan command (VLAN 20, as no specific VLAN is mentioned in the mac-vlan command, implying it uses the port’s default VLAN or another configured VLAN). But since the MAC address is not provided, we assume the port-based VLAN assignment (VLAN 20) applies.

The commands appear correct for a hybrid port with untagged VLAN 20 and MAC-VLAN enabled, but the effectiveness of the MAC-VLAN depends on Client 2’s MAC address.

Statement B (“Client 2 belongs to VLAN 20, and the commands for MAC address-based VLAN assignment on the switch are correct”) is potentially true if Client 2’s MAC is 0022-0022-0022, but without confirmation, we must consider the port’s default VLAN 20. However, the MAC-VLAN priority is set to 0, which is unusual (priority 0 typically indicates the lowest priority, and Huawei recommends non-zero values for MAC-VLAN). This suggests a potential configuration error or ambiguity.

Given the lack of MAC address confirmation and the unusual priority 0, Statement B is not definitively true, as the MAC-VLAN assignment may not function as intended or may conflict with port-based VLAN 20.

Client 3 (connected to GigabitEthernet0/0/3):

Configuration:

text

WrapCopy

vlan 30

#

interface GigabitEthernet0/0/3

port link-type trunk

port trunk allow-pass vlan 30

The port is configured as a trunk port with port link-type trunk and allows VLAN 30 traffic using port trunk allow-pass vlan 30.

Trunk ports carry tagged traffic for specified VLANs. For Client 3 (an end device, typically not a switch), the trunk port configuration is unusual because end devices usually connect via access ports, not trunk ports. However, if Client 3 is configured to send tagged frames for VLAN 30 (e.g., a VLAN-aware device like a phone or IP camera), it can belong to VLAN 30.

The commands are correct for a trunk port allowing VLAN 30, assuming Client 3 is configured to handle tagged VLAN 30 traffic.

Statement D (“Client 3 belongs to VLAN 30, and the commands for VLAN assignment on the switch are correct”) is true, assuming Client 3 supports VLAN tagging for VLAN 30.

Client 4 (connected to GigabitEthernet0/0/4):

Configuration:

text

WrapCopy

vlan 40

#

interface GigabitEthernet0/0/4

port link-type hybrid

port hybrid untagged vlan 40

The port is configured as a hybrid port with port link-type hybrid and set to carry untagged traffic for VLAN 40 using port hybrid untagged vlan 40.

Hybrid ports can carry untagged traffic for specific VLANs, so Client 4 belongs to VLAN 40 (untagged).

The commands are correct for a hybrid port assignment to VLAN 40.

Statement A (“Client 4 belongs to VLAN 40, and the commands for VLAN assignment on the switch are correct”) is true.

Evaluating Each Statement:

A: True – Client 4 belongs to VLAN 40 (untagged on a hybrid port), and the commands are correct.

B: Not definitively true – Client 2 belongs to VLAN 20 based on the port’s hybrid untagged VLAN 20, but the MAC-VLAN configuration with priority 0 is ambiguous without Client 2’s MAC address, and the priority 0 may indicate a configuration error. Thus, we cannot confirm the MAC address-based VLAN assignment is correct.

C: True – Client 1 belongs to VLAN 10 (access port), and the commands are correct.

D: True – Client 3 belongs to VLAN 30 (trunk port, assuming tagged traffic), and the commands are correct for a trunk port allowing VLAN 30.

Conclusion:

Statements A, C, and D are true based on the configuration and VLAN assignment rules. Statement B is not definitively true due to the ambiguity of Client 2’s MAC address and the unusual priority 0 in the MAC-VLAN configuration.

Answer: A, C, D

References from HCIA Datacom Documents:

HCIA Datacom V3.0, Chapter 4: VLAN Technologies – Access, Trunk, and Hybrid Port Configurations

HCIA Datacom V3.0, Chapter 4: MAC Address-Based VLAN Assignment – mac-vlan Command and Priority Settings

Huawei VLAN Configuration Guide (HCIA Datacom Certification Material) – Port Link Types and VLAN Assignment Rules

Detailed Explanation:The Time to Live (TTL) field in an IP packet is decremented by 1 each time the packet passes through a router. When the TTL reaches zero, the packet is discarded to prevent it from circulating indefinitely. (Reference: HCIA-Datacom Training Material, IP Packet Structure)

A (Correct) - Load Balancing: Link aggregation distributes traffic across multiple physical links, reducing congestion and improving performance.

B (Correct) - Improved Bandwidth: Multiple links act as a single logical link, increasing the total available bandwidth.

C (Correct) - Enhanced Reliability: If one link in an aggregated group fails, traffic is rerouted through the remaining links, improving network resilience.

D (Incorrect) - Improved Security: Link aggregation does not inherently improve security; it primarily enhances performance and fault tolerance.

Thus, the correct answers are A, B, and C.
