Free Practice Questions for Huawei H12-811_V1.0 Exam

Comprehensive Explanation: The PVID (Port VLAN ID) is the VLAN to which untagged data frames are assigned on a hybrid port. In this configuration, the port hybrid untagged vlan 4 6 command indicates that VLANs 4 and 6 are untagged, and the PVID will be the lowest untagged VLAN, which is VLAN 4. Tagged frames for VLANs 2, 3, and 100 will be forwarded as tagged, but untagged traffic will belong to VLAN 4 by default.

Detailed Explanation:The EUI-64 format splits a MAC address into two parts and inserts "FFFE" in the middle. The Universal/Local (U/L) bit is flipped, so a valid EUI-64 address would be 02E0-FCEF-FFFE-0FEC​.

VLAN Assignment Overview:VLAN (Virtual Local Area Network) assignment is a critical step in campus network planning. It involves logically segmenting a network to improve manageability, security, and performance. Huawei recommends various approaches based on specific needs.

Analysis of Options:

Option A: "VLAN assignment by service type"This method groups devices based on the type of service they require (e.g., voice, video, data). It helps in isolating traffic for different service types, improving QoS and security. This is a common practice in network planning​​.

Option B: "VLAN assignment by logical area"Logical area-based assignment groups devices based on their logical function in the network (e.g., core, access, distribution). It ensures proper segmentation and alignment with network topology​.

Option C: "VLAN assignment by geographic area"Assigning VLANs based on geographic areas (e.g., floors in a building, departments) helps localize traffic within a region, reducing unnecessary cross-network traffic​​.

Option D: "VLAN assignment by personnel structure"While this option suggests assigning VLANs based on organizational structure (e.g., employees, managers), it is not a typical practice in VLAN assignment. It lacks scalability and alignment with network topology, making it an inefficient approach​.

Correct Answers:The valid VLAN assignment methods in campus network planning are:

A. By service type

B. By logical area

C. By geographic area

Analysis of Possible Causes:

Option A: "The administrator account has been disabled" is a possible cause as a disabled account cannot access the system even if Telnet is enabled.

Option B: Incorrect because the Telnet service being disabled would affect all users, not just one administrator.

Option C: "The administrator account has been deleted" is a valid reason as a deleted account cannot log in.

Option D: "The user level of the administrator account has been changed to 0" is correct. User level 0 typically has insufficient privileges for Telnet access​​.

Detailed Explanation:

Option A is valid; the destination is defined in CIDR format (129.1.0.0/16) with a specified outgoing interface.

Option B is valid; it uses a subnet mask format and specifies a next-hop IP.

Option D is also valid with the destination and mask defined and a next-hop IP.

Option C is incorrect; the syntax reverses the destination and next-hop values.

(Reference: HCIA-Datacom Training Material, Static Routing Configuration)

Comprehensive Explanation: An ACL (Access Control List) is used to define rules for permitting or denying packets based on criteria such as IP addresses, protocols, or ports. However, the ACL only takes effect when it is applied to a service module, such as an interface or a firewall rule. This ensures that traffic is filtered according to the ACL rules as it passes through the device. Without being applied, the ACL rules are inactive and do not influence traffic.

In RSTP (Rapid Spanning Tree Protocol), the Backup port serves as a backup for the Designated port on the same bridge segment, not the root port. If the root port fails, the alternate port, not the backup port, takes over to maintain connectivity to the root bridge. The backup port does not have the capability to replace the root port​.

Detailed Explanation:RSTP (Rapid Spanning Tree Protocol) employs a synchronization mechanism with the proposal/agreement handshakes to prevent loops during topology changes. By synchronizing states between switches, RSTP avoids temporary loops while quickly transitioning ports to the forwarding state. (Reference: HCIA-Datacom Training Material, RSTP Mechanisms and Synchronization)

OSPF Network Types Overview:OSPF (Open Shortest Path First) supports different network types based on the underlying physical or logical topology:

A. Broadcast: OSPF assumes a fully meshed network, like Ethernet. DR/BDR elections occur.

B. Point-to-Point: A simple two-node network where no DR/BDR elections occur.

C. NBMA: OSPF operates over WAN technologies like Frame Relay. DR/BDR elections occur.

D. Point-to-Multipoint: OSPF operates on logically defined topologies where broadcast or multicast is not supported.

OSPF Flexibility:OSPF accommodates all these network types to ensure compatibility with a variety of link-layer technologies.

References: HCIA-Datacom V1.0 Certification Guide, Chapter 6: OSPF Fundamentals.
