Free Practice Questions for Axis Communications ANVE Exam

"The image shows a coaxial cable terminated with a BNC (Bayonet Neill–Concelman) connector. This type of connection is commonly used for analog video and some specialized network applications such as Axis video encoders."

— Axis Communications Academy, Network Video Fundamentals, 2022

"BNC connectors are standard for coaxial cabling in CCTV and video encoder installations."

— Axis Video Encoder Product Page

To calculate the storage required to record one hour of video from two cameras streaming at 6 Mbit/s each, we use the following steps:

Total bitrate for both cameras: 6 Mbit/s×2=12 Mbit/s6 \text{ Mbit/s} \times 2 = 12 \text{ Mbit/s}6 Mbit/s×2=12 Mbit/s

Convert Mbit/s to Mbyte/s: 12 Mbit/s÷8=1.5 Mbyte/s12 \text{ Mbit/s} \div 8 = 1.5 \text{ Mbyte/s}12 Mbit/s÷8=1.5 Mbyte/s

Calculate the total data for one hour: 1.5 Mbyte/s×3600 seconds=5400 Mbytes1.5 \text{ Mbyte/s} \times 3600 \text{ seconds} = 5400 \text{ Mbytes}1.5 Mbyte/s×3600 seconds=5400 Mbytes

Convert Mbytes to Gbytes: 5400 Mbytes÷1024=5.27 Gbytes5400 \text{ Mbytes} \div 1024 = 5.27 \text{ Gbytes}5400 Mbytes÷1024=5.27 Gbytes

Approximately, the storage required is 5.4 GB.

Germanium is used for thermal camera lenses because it is transparent to infrared wavelengths. This transparency allows infrared radiation to pass through the lens and reach the camera sensor, enabling the capture of thermal images. Germanium's optical properties make it an ideal material for thermal imaging applications. References: Axis Communications thermal camera specifications and technical documentation.

An IR cut filter is used to block infrared light during daylight hours to prevent it from interfering with the camera's sensor. This ensures that the colors captured by the camera appear natural. Without an IR cut filter, the infrared light can cause color distortions, resulting in unnatural-looking images. Axis cameras equipped with IR cut filters switch between day and night modes to optimize image quality in various lighting conditions, as explained in their technical documents and user manuals.

"Bandwidth is defined as the maximum rate of data transfer for a given network path, typically measured in bits per second (bps)."

— Axis Communications Academy, Network Video Fundamentals, 2022

"Bandwidth refers to the network’s capacity to carry data, not the amount of data produced or stored."

— Axis Web Article: Understanding Bandwidth

"For reliable identification of a person’s face, Axis recommends a pixel density of at least 250 pixels per meter (80 pixels per foot) on the target area."

— Axis Communications, Design Tool: Pixel Density Recommendations

"Identification: 250 px/m – Needed to identify a person beyond reasonable doubt."

— Axis Communications Academy, Network Video Fundamentals, 2022

When choosing between a camera with good low light performance and a thermal camera, the specific conditions of the installation site are crucial. For scenarios such as:

A. A primarily dark area like a subway or parking garage, a camera with good low light performance is necessary to capture detailed images in low light conditions where visible light is minimal.

C. In a parking lot for facial identification, good low light performance is essential to ensure that the camera can capture clear and recognizable facial features, even in low light situations.

Thermal cameras, while effective in detecting heat signatures, are not suitable for capturing detailed visual information such as facial identification.

Using a smoked (tinted) dome on a camera reduces light sensitivity because the tinted material filters the amount of light that reaches the camera sensor. This can result in lower image quality, especially in low-light conditions. The decrease in light sensitivity does not affect color fidelity, field of view, or infrared capabilities directly. For more information, refer to Axis Communications' technical notes on dome coverings and their impact on camera performance.
